Tunnel freezers: Low cost, suitable for freezing fish and meat, thick and heavy foods. The way of blowing is the from the top
Spiral freezers:Lower energy consumption,small floor occupying,retention time is much flexible,the adjusted range is large.The way of blowing is from the edgeways
Fluidized IFQ Tunnel Freezers: Suitable for freezing small and light materials, such as shrimp, strawberries, beans and granular materials. The way of blowing is from the bottom.
Parameters of IQF freezer as below sheet:
NO. | ITEM | CONTENT |
1 | Equipment Type | IQF Tunnel Freezer TF500A |
2 | Products | Fruits and vegetables |
3 | Output Capacity | 500kg/h |
4 | Inlet /Outlet Core Temperature | +15 degree Celsius /-18 degree Celsius |
5 | Inner Air Temperature | -40±2 degree Celsius |
6 | Overall Dimension | 6600mm*4000mm*2900mm L*W*H |
7 | Belt Width | 1100mm |
8 | Inlet /Outlet Device Length | 800mm |
9 | Inlet /OutletDevice Height | 1800mm |
10 | Retention Time | 10-50 minutes adjustable |
11 | Refrigeration Consumption | 85 KW (+40 degree C/-40 degree C) |
12 | Refrigerant | R22 |
1.Single belt for crust hardening applications
2.Fast and efficient cooling with multiple level conveyor belts
3.Belts can operate independently at various speeds or on a cascade principle
4.Low maintenance with a fully accessible stainless steel design
5.Design provides rapid freezing with lowest power consumption
6.Adjustable air speed for controlled processing of light and delicate products
7.Full freezing up to 1500 kg/hr
8.Cost effective alternative to running a cryogenic nitrogen tunnel freezer
(1) Stainless steel conveyor belt;
(2) Sandwich PUF panels 150mm thick, laminated by stainless steel sheet both sides; floor panels are equipped;
(3) Doors are equipped with frame heating device;
(4) Aluminum evaporators, different fin pitches;
(5) Axial fans: stainless steel air box, aluminum blades;
(6) Full welded stainless steel water discharging plate is installed on top of floor panels. It will bring defrosting water out of cabinet through stainless steel draining pipes;
(7) The inlet device, outlet device and all structure parts are made of stainless steel;
(8) Control panel is made of stainless steel;
(9) Schneider or Siemens electric components;
(10)SEW speed reducer.
1. High production capacity in a smaller footprint than conventional spiral freezers.
2. Low operating cost through maximized cryogen efficiency.
3. Higher frozen product quality from a quicker freeze.
4. Reduced labor for cleaning and improved food safety through hygienic design.
5. Less product dehydration through reduced freezing time resulting in higher product yield.
Packaging | ||
Size | 123 (L) * 456 (W) * 789 (D) | |
Weight | 1.2 T | |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
Model:TF Series | Output | Installed Power | Refrigeration Consumption | Dimension L*W*H | Belt Width |
TF100 | 100kg/h | 2.25kw | 15kw | 7.4*1.5*2.2m | 1000m |
TF150 | 150kg/h | 2.95kw | 21kw | 8.0*1.8*2.3m | 1300mm |
TF200 | 200kg/h | 4.5kw | 30kw | 10.2*1.8*2.3m | 1300mm |
TF300 | 300kg/h | 6.5kw | 43.5kw | 11.2*2.3*2.3m | 1800mm |
TF500 | 500kg/h | 10.3kw | 75kw | 13.5*3.0*2.5m | 2500mm |
TF1000 | 1000kg/h | 19.8kw | 142kw | 22.9*3.0*2.5m | 2500mm |
TF1500 | 1500kg/h | 28.6kw | 225kw | 26.4*3.5*2.5m | 3000mm |
Q: Minimum order quantity?
A: Any order quantity is welcomed. Bulk order quantity will enjoy a more favorable price.
Q: Delivery time?
A: Within 15 days after received payment. If there is stock, could ship out within 2 days after received payment. Check with us before place an order.
Q: How to pay?
A: You could pay by credit card or T/T via Alibaba Trade Assurance system.
Q: Machine has warranty?
A: Yes. Sure machine covers one year parts warranty.
Q: Could we show our logo and company information on our machine?
A: Yes. It is ok.
Q: Could you provide us machine photo, specification, catalogue, ads material for promotion use in our local market?
A: Yes. Sure is willing to do this.
