Пищевой нержавеющей стали 4000L 5000L 6000L Бак Охлаждения де молока для фермы охлаждающий
- Категория: Dairy Processing Machines >>>
- Поставщик: Wenzhou,Ace,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 2856.47 $* | 2999.88 $* |
| Aug-15-2025 | 2832.80 $* | 2974.50 $* |
| Jul-15-2025 | 2376.66 $* | 2495.75 $* |
| Jun-15-2025 | 2784.11 $* | 2923.81 $* |
| May-15-2025 | 2424.99 $* | 2545.72 $* |
| Apr-15-2025 | 2736.98 $* | 2873.55 $* |
| Mar-15-2025 | 2712.10 $* | 2848.21 $* |
| Feb-15-2025 | 2688.50 $* | 2822.15 $* |
| Jan-15-2025 | 2664.69 $* | 2797.60 $* |
Характеристики
Food Grade Stainless Steel 4000L 5000L 6000L Tank Cooling De Milk For Farm Milk Cooling Tank
Custom Made 100L- 30,000L Cooling tanks, 20 Years Of Experience. Reasonable Price And Best Service, CE Certificated Products.Sold to Over 180 Countries.Advanced Technology.Contact us for the offer.
Video
Products Description
Description
The refrigerated mixing and storage tank is made up tank body, agitator, refrigerating unit and control box. The tank body is made
of stainless steel 304, and be minutely polished. Insulation is filled by polyurethane foam, light weight, good insulation
properties.
of stainless steel 304, and be minutely polished. Insulation is filled by polyurethane foam, light weight, good insulation
properties.
1. Material: Stainless steel 304 316L
2. Equipped with refrigeration system
3. Cooling jacket, PU insulated (50-80mm)
4. Capacity: 100L-30,000L
5. Consist of control box, refrigeration group, inlet, CIP cleaning Head,
Agitation motor, manhole, temperature meter, tank body, outlet.
6. Working temperature: 35-4 Cels
7. Refrigerant: R404A(recommended)or R22
8. Custom made available
9. Vertical and horizonal two options
2. Equipped with refrigeration system
3. Cooling jacket, PU insulated (50-80mm)
4. Capacity: 100L-30,000L
5. Consist of control box, refrigeration group, inlet, CIP cleaning Head,
Agitation motor, manhole, temperature meter, tank body, outlet.
6. Working temperature: 35-4 Cels
7. Refrigerant: R404A(recommended)or R22
8. Custom made available
9. Vertical and horizonal two options
Model | Volume(L) | Compressor Powr(KW) | Dimension of tank(D*L(mm) | Agitator power(kw) | Agitator speed(r/min) | |||||
ACE-500 | 500 | 4.5 | Φ800x900 | 0.55 | 36RPM | |||||
ACE-800 | 800 | 8 | Φ1000x900 | 0.75 | ||||||
ACE-1000 | 1000 | 12 | Φ1200x1000 | 0.75 | ||||||
ACE-2000 | 2000 | 15 | Φ1200x1000 | 1.5 | ||||||
ACE-3000 | 3000 | 15 | Φ1400x2000 | 2.2 | ||||||
ACE-6000 | 6000 | 30 | Φ1600x3000 | 3.0 | ||||||
ACE-8000 | 8000 | 30 | Φ1800x3000 | 3.0 | ||||||
ACE-10000 | 10000 | 44 | Φ2000x3500 | 3.0 | ||||||
We can customize the cooling tank according to customer requirements. | ||||||||||
Principle and structure of direct cooling milk tank:
Milk refrigeration tank is mainly composed of tank body, mixer, scrubber, refrigeration unit and electrical control box. The milk cooling tank is a horizontal elliptical body. Polyurethane rigid foam board is adopted between the inner and outer tanks. The material has the thermal insulation layer with low thermal conductivity, light weight, high strength and low water absorption, and has good heat preservation performance. The product has advanced design and manufacturing technology, reliable performance, cooling, thermal insulation performance and health standards are in line with the advanced level.
Features of direct cooling milk tank:
1. The tank wall adopts advanced plate evaporator to directly exchange heat and refrigeration with milk.
2. The refrigeration compressor is imported from France. It is equipped with reliable neutral point protector, which will not burn out the motor due to overload or system failure.
3. All tanks are made of SUS304 or 316 stainless steel with automatic pressure cleaning and manual and automatic mixing devices,
4. The new technology of polyurethane foam is used in the insulation layer, which has good thermal insulation performance.
Milk refrigeration tank is mainly composed of tank body, mixer, scrubber, refrigeration unit and electrical control box. The milk cooling tank is a horizontal elliptical body. Polyurethane rigid foam board is adopted between the inner and outer tanks. The material has the thermal insulation layer with low thermal conductivity, light weight, high strength and low water absorption, and has good heat preservation performance. The product has advanced design and manufacturing technology, reliable performance, cooling, thermal insulation performance and health standards are in line with the advanced level.
Features of direct cooling milk tank:
1. The tank wall adopts advanced plate evaporator to directly exchange heat and refrigeration with milk.
2. The refrigeration compressor is imported from France. It is equipped with reliable neutral point protector, which will not burn out the motor due to overload or system failure.
3. All tanks are made of SUS304 or 316 stainless steel with automatic pressure cleaning and manual and automatic mixing devices,
4. The new technology of polyurethane foam is used in the insulation layer, which has good thermal insulation performance.
Details Images
Packaging & Shipping
We are experienced in the whole packing and shipping process,and we will be responsible for any damage made during shipping and send clients replacements for free.
* Sufficient inner protection with different materials, including bubble bag, foam board and others.
* Qualified wooden package or carton for different products or as customer require
* Strict packing process to ensure the safety and completeness of the goods
* Sufficient inner protection with different materials, including bubble bag, foam board and others.
* Qualified wooden package or carton for different products or as customer require
* Strict packing process to ensure the safety and completeness of the goods
Certifications
FAQ
Q | Are you trade or manufacturer? | ||||||
A | We are a factory with an international sales company specialized in support for global distributors. | ||||||
Q | Can you provide instant technical consulting services? | ||||||
A | We are able to discuss technical details and offer suggestions over the phone in English. You can get the answers in minutes, instead of days. | ||||||
Q | What's the difference between Ready-To-Ship and Customized products? | ||||||
A | Some of RTS standard products are in stock and ready to ship in 2-3 days. We can also quick design and make the drawings for customer requirements, then begin the production. | ||||||
Q | What is the payment terms? | ||||||
A | We accept Alibaba Trade Assurance Order, also can T/T and L/C. | ||||||
Q | How to choose the shipment way? | ||||||
A | It is according to the order quantity, delivery time, costs and customs policy etc. (Or decide by customers) | ||||||
Q | How about the after-sales service? | ||||||
A | Fast after-sales support. Our products have a one-year warranty and free permanent consulting services. | ||||||
