The automatic ultrasonic thick aluminum wire welding machine MD-CWS3753A adopts a digital automatic frequency tracking ultrasonic system, a digitally controlled pressure adjustment function, a first-class image recognition device, and a fully closed-loop motion control circuit. Realize the full automation of China's thick aluminum wire bonding machine!
MD-CWS3740A is mainly used in the welding of 18650 Tesla batteries, 26800 lithium batteries, square batteries and other products. Using advanced image recognition technology and automatic positioning technology, the automatic and accurate positioning of the solder joints is realized. The powerful and abundant digital ultrasonic ensures stable and reliable solder joint quality. The fully automatic frequency tracking ultrasonic system and reasonable welding head design guarantee the quality of the welding joints. The original digital pressure control system ensures constant pressure output to ensure the consistency of solder joints. The precise mechanical transmission mechanism, reliable industrial computer and software with independent intellectual property rights ensure the accuracy of the welding position. It has multiple fault alarms and shutdown functions such as failure of welding, abnormal pay-off, etc., which greatly reduces the rate of defective products and greatly improves the output. It is more maneuverable and user-friendly. Using computer-controlled Chinese operation interface, new employees can operate by themselves in one day of training, and can be proficient in one month. Operation, one person can operate multiple machines at the same time, greatly improving work efficiency.
Products Description
Manual (front-end station) loading, automatic identification and positioning, automatic bonding, manual (flowing into the back-end station) unloading. This assembly machine is dedicated to the bonding production of battery products specified by the customer. Non-universal equipment. If other products are needed, they need to be modified and used according to actual conditions. This machine is mainly composed of frame assembly, XYZC feeding assembly, automatic feeding mechanism, wire feeding mechanism, jig positioning and pressing assembly, welding head mechanism and console. XYZ module uses precision ball screw drive, the distance repeat positioning accuracy is less than ±0.02mm, and the angle positioning accuracy is ±1°. The control system adopts industrial computer + motion control card to control the operation of the private server motor. The equipment is easy to operate and maintain, the control interface is friendly, and the parameter setting is digital; it is more flexible. Adopt quick clamp clamping, single button start, easy and safe for personnel to unload materials. Left-in and right-out can be used for online multi-section track conveying, which can be directly connected to the production line.
Specification
Power supply
220VAC±10%, 50Hz, reliable grounding, the maximum consumption rate is about 800W
Ultrasound frequency
60KHz
Ultrasonic power
0~30W, automatic switching between first and second welding
X axis
Using imported accessories, the repeat positioning accuracy can reach ±0.02mm
Y, Z axis
Driven by precision ball screw
Z axis
50mm.C axis: plus or minus 90°
Weldable aluminum wire diameter
125~ 500um(5～20mil)
Work area
XY axis up to 400 × 400 (can be customized according to customer requirements)
Ultrasound time
10~500ms, multi-channel
Welding pressure
50~1200g, multi-channel
Welding angle
±90 degrees
Welding speed
Approximately each thread/1.5 seconds
visual system
(Note: The size of different wire diameters also has an absolute relationship with the production speed; the moving distance between different batteries will have a big difference in the production speed; the welding easiness of the material is different, and the speed is different.)
PR lighting
PR microscope magnification is 0.5 times
Dimensions
White light, adjustable brightness
weight
Approximately 985mm*1030mm*1400mm(L*W*H)
