YONGSHENG 5G умный светильник с дистанционным мониторингом дорожного мониторинга CCTV стальной полюс 1985 года
- Категория: Lamp Poles >>>
- Поставщик: Shijiazhuang,Economic,And,Technological,Development,Zone,Yongsheng,Lamp,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.89 $* | 0.66 $* |
| Aug-16-2025 | 0.95 $* | 0.3 $* |
| Jul-16-2025 | 0.68 $* | 0.34 $* |
| Jun-16-2025 | 0.17 $* | 0.30 $* |
| May-16-2025 | 0.52 $* | 0.53 $* |
| Apr-16-2025 | 0.8 $* | 0.54 $* |
| Mar-16-2025 | 0.39 $* | 0.56 $* |
| Feb-16-2025 | 0.15 $* | 0.39 $* |
| Jan-16-2025 | 0.47 $* | 0.82 $* |
Характеристики
YONGSHENG waterproof 5G remote monitoring smart lamp pole road monitoring CCTV steel pole since 1985 years factory for crossway, highway, etc.
Product name | Monitoring pole |
Height | 3-12m |
Surface treatment | Hot dip galvanizing meets Chinese standard GB / T 13912-2002 or American standard ASTM A123 or AS / NZS 4680:2006 can be powder coated or painted according to customer requirements |
Material | Hot rolled steel Q235,Q345,Q420,Q460,ASTM A527 A36,GR50,GR65,ST-37,ST-44,ST-52,S355JR,S355J2G3,SS41,SS50,SS55 etc. |
shape | Polygonal, Round,Equal diameter pipe, reducer pipe, Conical, etc. |
Thickness | 2-12mm |
Welding | Welding conforms to the AWS D1.1 standard. Automatic method of CO2 welding or submerged arc welding No cracks, scars, overlaps, layers or other defects Internal and external welding makes the rod more beautiful If the customer needs any other welding requirements, we can also adjust according to your requirements. |
baseplate | Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client's requirement. |
Connection method | Combined with insert mode, flange mode.,Face-to-face joint mode connecting rod. |
Color | Surface spray, color optional |
Lifespan | More than 25 years, it is according to installing environment |
Applications | Traffic road, crossroad, school, government, communitie, border defense, airport, highway, etc. |
Product name | 19YS-JKG-8L-H6-L3-1-01 | |||||
Pole | height | type | Upper /Lower Caliber(mm) | Thickness(mm) | Pole flange(mm) | Pole weight(kg) |
| 6 | octagonal | 180/240 | 3.75 | φ450*16 | 141 |
Cross arm | length | type | Upper /Lower Caliber(mm) | Thickness(mm) | Cross arm flange(mm) | Cross arm weight(kg) |
| 3 | octagonal | 90/140 | 3 | 300*300*11.75 | 47 |
Material | Height Opening(mm) | Auxiliary accessories | Foundation size(mm) | Embedded parts | ||
Q235 | 500 | Access door, fixing bolt,Lightning pole | 700*700*1000 | National standard screw M20*1000*6 Base boardφ450*4.75mm | ||
Application | ||||||
Traffic road, crossroad, school, government, communitie, border defense, airport, highway, etc. | ||||||
Above is our standard parameter. We can also customize it according to your requirements. | ||||||
