5 м Samll кран с сталкивается пультом дистанционного управления для древесины деревянный
- Категория: Forestry Machinery >>>
- Поставщик: Jinan,Sinoheng,Import,And,Export,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.44 $* | 0.43 $* |
| Aug-17-2025 | 0.68 $* | 0.92 $* |
| Jul-17-2025 | 0.89 $* | 0.65 $* |
| Jun-17-2025 | 0.34 $* | 0.61 $* |
| May-17-2025 | 0.79 $* | 0.4 $* |
| Apr-17-2025 | 0.15 $* | 0.84 $* |
| Mar-17-2025 | 0.12 $* | 0.62 $* |
| Feb-17-2025 | 0.26 $* | 0.79 $* |
| Jan-17-2025 | 0.42 $* | 0.15 $* |
Характеристики
5.5m Samll Crane with grapples with remote control
and Electric-hydraulic Porportional Valve and Mobile base
Crane with Grapples Technical Specification :
5.5m Mobile Crane with grabber | |||
Max. Crane boom length | 5.5m | ||
Rotary torque | 10 KN.M | ||
Rotary angle | 380° | ||
Rotary oil cylinder quantity | 4 pcs | ||
Lifting capacity at 5m | 600KG ( Enhanced boom and cylinder change bigger ) | ||
Lifting capacity at complete extend | 520 | ||
Grabber swing brake | Yes | ||
Telescopic boom structure | With 1m telescopic boom | ||
Recommended hydraulic oil flow | 25-50 L/min | ||
Working pressure | 18 Mpa | ||
Standard rotary motor | GR-30(3T) | ||
Standard grabber | 0.18m3 | ||
Total weight (Without outrigger and valve blocks ) | 636KG | ||
Column height | Including base height | About 1.8m | |
| Excluding base height | About 1.36m | |
Base size | 3000x2000x450mm | ||
Main configuration | 1. Mobile type crane with grabber 5.5m boom length 2. With mobile base ( Wheels can be disassembled ) 3. Electric hydraulic Pump (380V 50HZ) 4. Rotary motor GR-30 (3 T) 5. 0.16m3 Grabber, also can be 0.18m3 grabber 6. Remote control and Electric-hydraulic proportional valve | ||
