Ламинатор для Резки Пленки ламинатор Флим полиуретановая ламинатная ткань автоматический пластик новый Trink мобильный ПВХ
- Категория: Laminating Machines >>>
- Поставщик: Zhejiang,Cidihuakai,Import,And,Export,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 86870.22 $* | 91214.76 $* |
| Aug-19-2025 | 86140.76 $* | 90447.79 $* |
| Jul-19-2025 | 72270.60 $* | 75884.16 $* |
| Jun-19-2025 | 84680.38 $* | 88914.98 $* |
| May-19-2025 | 73730.81 $* | 77417.97 $* |
| Apr-19-2025 | 83220.20 $* | 87381.26 $* |
| Mar-19-2025 | 82490.92 $* | 86615.61 $* |
| Feb-19-2025 | 81760.67 $* | 85848.79 $* |
| Jan-19-2025 | 81030.67 $* | 85082.39 $* |
Характеристики
Product Picture
Sample Pictures
Video Description
Product Describe
Medical, Food, Electronic Packaging Products will always require high barrier packaging, sealing and even thickness.Normally, such business will require using Aluminum Foil, PET film, BOPP film etc, compounding them together to acheive high barrier effect. We continue our study of technology, formula and engineering skill of such business, to make sure our clients can always have better supports from us.
Machine Components
1. It can maintain a stable running of 120M/Mi. Full Automatic of Auto-Splicer, Tension Control and EPC, with high efficiency and high reliability.
2.This model is double preciseness than paper base lamination machine, no matter tension, coating variation and trimming and epc, all require as less as possible.
3. there is no certain model of this one, Almost all are specialy custermized on the base material and formula of the customer's products, and are designed with high pertinence. To make sure maximum effort of production.
4.We have full supply resources of each key parts of machine, including gears, glue coating machine, screws and T-Dies. In different brands and different applications. To make sure we can always supply the best to our clients according to their product.
Product Paremeter
S/N | Item | Paremeter |
1 | Model | BT-JDLM-PCE |
2 | Screw Diameter | φ110 mm |
3 | L/D | 33:1 |
4 | Product Width | 600-1000MM |
5 | Coating | 0.01-0.10MM |
6 | Coating Material (Lamination Grade) | LDPE , LLDPE , PP, |
7 | Designed Line Speed | 185M/MIN |
8 | Max Extrusion | 200kg/h |
9 | Main Motor | 45 kw |
10 | Total Power | 190KW |
11 | Main Un-Winder | ≤φ600 MM |
2nd Un-Winder | ≤φ500 MM | |
12 | Winder | ≤φ800 mm |
13 | Weight | 12T |
14 | Overal Demension | 9000x15000x3200MM |
15 | Power Supply | 380/3/4/50(Volt/Ph/Line/Hz) |
Product configuration
