Модуль камеры CMOS IMX317 модуль Hd 4K HD USB 8 Мп с датчиком

Модуль камеры CMOS IMX317 модуль Hd 4K HD USB 8 Мп с датчиком

Категория: Electronic Data Systems >>>
Поставщик: Shenzhen,Brilliant,Cmos,Technology,Co.,Ltd.

Цена:40,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	48.26 $*	50.85 $*
Aug-18-2025	47.52 $*	49.62 $*
Jul-18-2025	40.90 $*	42.88 $*
Jun-18-2025	46.86 $*	48.13 $*
May-18-2025	40.27 $*	42.4 $*
Apr-18-2025	46.80 $*	48.56 $*
Mar-18-2025	45.10 $*	47.49 $*
Feb-18-2025	45.74 $*	47.58 $*
Jan-18-2025	44.71 $*	46.2 $*

Характеристики

Product Description

Product Name	Sony IMX317 USB2.0 UVC Camera Module
Sensor	1/2.5’’ Sony IMX317
Resolution	3264×2448@30FPS
FOV（Diagonal）	80°
Focus type	Fixed focus
Compression format/Video stream form	MJPEG / YUV2 (YUYV)
Shutter Type	Shutter Type
Max Dynamic Range	TBD
S/N ratio	TBD
Cable Length	/
Object distance	2cm to 100m
Dimension	26mm50mm23.9mm
UVC compliant	USB Video Class（UVC）
Support OS	WinXP/Vista/Win7/Win8; Linux with UVC（above linux-2.6.26), Android 4.0 or above with UVC, raspberry pi
Support SDK	NO

Key Features:

1. IMX317 4k USB2.0 Camera Module.
2. Most effective pixels is 3264(H) x 2448(V)@15FPS (MJPEG).
3. Fixed focus,UVC compliant, plug and play interface standard.
4. Fast speed and large target area
5. Can be equipped with small lens or large lens at the same time
6. The image is delicate, super clear, and the resolution is 8MP
7. Original imaging ratio; 16:9
8. Main application video conference, live broadcast 4H

Details Images

8MP usb2.0 UVC camera module is used for Sony IMX317CMOS image sensor , the reslution is 3264×2448 frame rate is 30FPS. It can be applied to face recognition, high shot equipment.

Standard USB Cable length is 1meter. If you want to longer or shorter, kindly tell us.

UVC standard,support WinXP/Vista/Win7/Win8; Linux with UVC（above linux-2.6.26; MAC-OS X 10.4.8 or later);Android 4.0 or above with UVC, raspberry pi

26mm*50mm*23.9mm , Supper HD 4K Lens

Product Application

Packing&Shipping

1000pcs per carton

Company Introduction

Shenzhen Brilliant Technology Co., Ltd. is specialized in manufacturing camera module, mainly providing USB interface
cameramodule, MIPI / DVP interface camera module, miniature endoscope module. We can provide SDK for most USB camera modules,support OEM service.

Class 10K Workshop

Our Services & Strength

R&D Department: 5 people, we can support SDK for USB Camera module

Lable: Different styles lable for your choice

FAQ

1. How to buy our product?

You can buy the products from our company directly. Normally the procedure is, sign the contract, make
the payment by T/T, Paypal, Alibaba or Western Union, then ship the goods to your address.

2. What's the warranty?

The free warranty is 2years from the date of commissioning qualified. During the free warranty period, if there's any fault
because of our produce, it's our duty to repair it and change the fault assembly for free.

3. Can we visit your camera module manufacturer?

Of course, we will arrange everything if you can tell me in advance. So please feel free to contact me and I will do my best tomake your trip worthwhile.

4. How to customize camera modules as our requirement?

For customization service, it's warmly welcome.
Our company has been in camera module industry for over 10 years and has a rich experience on customized services.
We'll try our best to meet your requirements.
In order to know well clients' requirements, we should know parameters as below,
a) Form factor
b) Dimensions
c) Pixel
d) Frame rate
e) FOV-horizontal, diagonal, vertical
f) Interface-MIPI, USB, ANALOG etc.
g) Pin description
h) Image Effect, monochrome or colorful
i) Any other function requirement? IR Light, IR Cut? What's the wavelength?
