Полностью автоматическая машина для резки наклеек легко использовать этикеток рулонная листов
- Категория: Станки для обработки бумаги >>>
- Поставщик: Suzhou,Flying,Man,Assembly,Automation,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.39 $* | 0.68 $* |
| Aug-19-2025 | 0.50 $* | 0.42 $* |
| Jul-19-2025 | 0.45 $* | 0.53 $* |
| Jun-19-2025 | 0.35 $* | 0.85 $* |
| May-19-2025 | 0.18 $* | 0.96 $* |
| Apr-19-2025 | 0.33 $* | 0.28 $* |
| Mar-19-2025 | 0.2 $* | 0.4 $* |
| Feb-19-2025 | 0.49 $* | 0.74 $* |
| Jan-19-2025 | 0.36 $* | 0.16 $* |
Характеристики
Video Description
Products Description
Feature
This cutting machine employs man-machine interface + PLC system equipped with pneumatic pushing device.
- For half cut-off with multi-cut, full cut-off with one-cut.
- Five different cutting length can be set.
- Different cutting quantity and circulation time also can be set to improve cutting efficiency.
- High precision, low loss, easy operation.
Main functions
- Feed material and return material by pressing the button on touch screen.
- Preset total cutting quantity.
- Preset cutting length.
- Preset cutting speed.
- Preset cut quantity each time ( applied for hot cutting).
- Display cutting quantity finished.
- Half cut-off with multi-cut.
- Full cut-off with one-cut.
- Five different cutting length can be set.
- Different cutting quantity and circulation time can be set.
- Return to ZERO.
- Preset total cutting quantity.
- Preset cutting length.
- Preset cutting speed.
- Preset cut quantity each time ( applied for hot cutting).
- Display cutting quantity finished.
- Half cut-off with multi-cut.
- Full cut-off with one-cut.
- Five different cutting length can be set.
- Different cutting quantity and circulation time can be set.
- Return to ZERO.
Product Paramenters
SPECIFICATIONS FOR AUTOMATIC ROLL TO SHEET CUTTING MACHINE | ||||
Model | FMKY-360Q | FMKY-500Q | ||
Cutting length | 0.1~9999.9 mm | 0.1~9999.9 mm | ||
Cutting Width | 0-360 mm | 0-500 mm | ||
Cutting speed | 0-130 cuts/min | 0-130 cuts/min | ||
Cutting precision | ±0.05 mm | ±0.05 mm | ||
Power | 1.5 kw | 1.5 kw | ||
Voltage | 220 v/380 v | 220 v/380 v | ||
Counter | Meter counter + Speed Display Board | |||
Machine Sizes (L*W*H) | 870x1050x1070 mm | 1010x1150x1070 mm | ||
Machine Weight | 240 kgs | 270 kgs | ||
Touch Screen
You can set all parameter in touch screen,such as the length,batch quantity,total quantity,cutting speed,etc.
It's convenient for workers to operate the machine.
It's convenient for workers to operate the machine.
Rubber roller to feed material
The rubber roll is connected with servo motor,which could feed material with high precision,reach ± 0.1mm.
Cutting Blade
Material:SKH-51
Original:Japan
Lifetime:About 20 million times cuts.
Scissor-type cutting blade,durable with highest hardness 65HRC. Easy to adjust,sharp,maintain and change.
Original:Japan
Lifetime:About 20 million times cuts.
Scissor-type cutting blade,durable with highest hardness 65HRC. Easy to adjust,sharp,maintain and change.
We provide below optional parts, you may choose to install on the cutting machine, and also we offer the customization service based on your requirement.
- Photo sensor:cutting material at a specified position.
- Kiss cutting unit: half cut- Automatic unwinding device
Photo Sensor
If added photo sensor for cutting machine,it can cut the printed material. The photo sensor will sense the printed marking and make sure the cutting blade cut the material at a specified place.
Kiss cutting
Material:Utility knife and fixture
This unit can finish kiss cutting .Below anvil is connected with springs,which could absorb shock and make sure the kiss cutting
well.Easy to adjust and maintain.
This unit can finish kiss cutting .Below anvil is connected with springs,which could absorb shock and make sure the kiss cutting
well.Easy to adjust and maintain.
Automatic unwinding device
This unwinding device is controlled by motor,you can adjust the speed.
It has sensor to send the material automatically.It could supports about 30KG weight.inflatable air shaft with 3 inch OD.
It has sensor to send the material automatically.It could supports about 30KG weight.inflatable air shaft with 3 inch OD.
Product Application
Sizing cutting for conductive fabric, foam , diffuser, reflector film, double-sided adhesive tape, nickel plate, PET,PC,PE insulation paper, copper /aluminum foil and all kinds of adhesive tapes.
Whole Service
Technical Service
- Free sample testing and video for your reference.
- Technical support: Professional engineers’ team to help you design a whole-set product line to get highest profit with lowest cost and offer you technical support any time.
Training service
Free training in our factory available before delivering machines.
Engineers available to service machinery overseas.
Engineers available to service machinery overseas.
After Sales Service
- Every customer can get one piece of English operation manual, a total working video for machines ,details on every button function ,normal notice when operation.
- One-year warranty, whole life technical support.
- One-year warranty, whole life technical support.
- 24 hours technical support, we will do our best to help our customers solve problems.
- We offer not only the products, but also the solutions. Plenty of cooperated professional supplier for mold or other necessary equipment make it possible for us to offer our customers big convenience to complete their production line in high quality with low cost in a short time.
PACKAGE
We use exporting standard packing. First to wrap PE film around the machine, then packed by plywood case to ensure the package enough safe and strong. It’s easy for forklift to upload and download and safety transportation. We also can pack the machine according to customers special requirement.
SHIPPING
Usually we suggest customers choose ocean shipping to ship machinery, or air transport for small machine or urgent order. We also supply shipping service with our cooperation shipping forwarder to help customers to deliver the machinery in first time.
company profile
FAQ
Q: Are you a factory or trading company?
A: We are a factory and manufacturer.
Q: Where is your factory located in? How can I visit there?
A: Our factory is located in Kunshan city, Jiangsu province, and our detailed address is: No.1008, Xiangshi Road, Bacheng Town, Kunshan City, JiangSu Province, China.
It’s only 40 minutes' away from Shanghai Hongqiao airport by car, and 18 minutes' away from Shanghai railway station by high-speed rail. The traffic is very convenient.
Q: what are your main products?
A: Our main products are high speed precision die cutting machines, cutting machines, slitting machines, laminating machines and printing machines.
Q: Which industries can use your machines ?
A: All industries need to cut (include full cutting and kiss-cutting), slit, laminate, die cut raw materials can use our machines. Mainly used for material before and after cutting and/or printing.
Q: How to control the quality in your factory?
A: Quality is priority. We control the quality of our products strictly, from the incoming materials to the finished products. Our factory has obtained CE Certification.
Q: If there are no machines available from your list, could we customize non-standard machines from you?
A: Yes, we have our own professional design engineers, and can customize products according to your requirement. 30% of our current customer need customization on their machines.
Q: What's the trade term?
A: EXW, FOB, CFR, CIF or DDU are all workable based on customer’s requirement.
Your question will be highly appreciated.
A: We are a factory and manufacturer.
Q: Where is your factory located in? How can I visit there?
A: Our factory is located in Kunshan city, Jiangsu province, and our detailed address is: No.1008, Xiangshi Road, Bacheng Town, Kunshan City, JiangSu Province, China.
It’s only 40 minutes' away from Shanghai Hongqiao airport by car, and 18 minutes' away from Shanghai railway station by high-speed rail. The traffic is very convenient.
Q: what are your main products?
A: Our main products are high speed precision die cutting machines, cutting machines, slitting machines, laminating machines and printing machines.
Q: Which industries can use your machines ?
A: All industries need to cut (include full cutting and kiss-cutting), slit, laminate, die cut raw materials can use our machines. Mainly used for material before and after cutting and/or printing.
Q: How to control the quality in your factory?
A: Quality is priority. We control the quality of our products strictly, from the incoming materials to the finished products. Our factory has obtained CE Certification.
Q: If there are no machines available from your list, could we customize non-standard machines from you?
A: Yes, we have our own professional design engineers, and can customize products according to your requirement. 30% of our current customer need customization on their machines.
Q: What's the trade term?
A: EXW, FOB, CFR, CIF or DDU are all workable based on customer’s requirement.
Your question will be highly appreciated.
