Характеристики


Quick IQF Freezing Freezer

The tunnel freezer is a high-efficiency quick freezing machine with relatively simple structure. It is mainly used for
quick-freezing processing of pasta, seafood, poultry, vegetables, fruits, dairy products and other foods. Freezing capacity can be 100kg/h-2000kg/h.
iqf mango tunnel
iqf mango tunnel
FEATURES AT A GLANCE
1.Single belt for crust hardening applications
2.Fast and efficient cooling with multiple level conveyor belts
3.Belts can operate independently at various speeds or on a cascade principle
4.Low maintenance with a fully accessible stainless steel design
5.Design provides rapid freezing with lowest power consumption
6.Adjustable air speed for controlled processing of light and delicate products
7.Full freezing up to 1500 kg/hr
8.Cost effective alternative to running a cryogenic nitrogen tunnel freezer
PRODUCT SPECIFICATIONS
NO.
ITEM
CONTENT
1
Equipment Type
Tunnel Freezer TF100
2
Belt Type
Stainless steel material
3
Overall Dimension
7340mm*1440mm*2100mm L*W*H
4
Belt Width
1000mm
5
Tunnel Passable Height
100mm
6
Inlet Device Length
600mm
7
Outlet Device Length
600mm
8
Inlet & Outlet Device Height
830mm
9
Defrosting Method & Interval
By Water every 12 hours
10
Refrigeration Consumption
17 KW (+40 degree C/-40 degree C)
11
Evaporating Area
180 square meters
12
Compressor Model
ITALY FRASCOLD 2Z25-84.42Y
13
Refrigeration Capacity
17.34 KW (+40 degree C/-40 degree C)
14
Refrigerant
R507a/R404a/R22
15
Condensing Type
Air cooled
16
Installed Power for tunnel freezer
2.75KW
17
Installed Power for Compressor System
13.03KW
Details Images


iqf mango tunnel
iqf mango tunnel
iqf mango tunnel
iqf mango tunnel

Send inquiry to ➣

https://message.alibaba.com/msgsend/contact.htm?spm=a2700.details.cordpanyb.dmessage.66da385fXrg9He&action=contact_action&domain=1&id=1600146728852&id_f=IDX1huRmufHPLRJyrrTAea_BEXyI9VXVw1k4pkRuYbS0RKsykZNE5jivHmRwN8Lro_Lq&mloca=main_en_detail&tracelog=tracedetailfeedback&umidToken=B0679652e4c096bc2709f681411675f71
Successful Project
iqf mango tunnel
Projectin South Korea
iqf mango tunnel
Project in USA
iqf mango tunnel
Project in Mexico
Company Profile
iqf mango tunnel
introduction:
We specialized to produce machines for food industry,include cooling & freezing equipment,bakery equipment,kitchen equipment,ice cream machines,processing lines for meat,dumplings,fishes,shrimps,fruits and vegetables,candies,chocolates and snack foods.Besides,we also provide site installation and commissioning services, and craft consultation services.
Our machines have been exported to North America,South America, Europe,Australia,Africa,Southeast Asia and the Middle East areas.Our technicians have been sent to Mexico,Canada,Zambia,Costa Rica,United States,South Korea and many other countries for machines’installation and commissioning.

Customer Photos
iqf mango tunnel
iqf mango tunnel
iqf mango tunnel
iqf mango tunnel
FAQ
Q1: Do you receive customized order?
A: Yes, ODM & OEM are welcomed.

Q2: What's the lead time?
A: According to the order quantity, small order usually need 40-45 days, big order need negotiation.

Q3: What's your warranty terms?
A: We supply 12 months warranty time.

Q4: What's your payment terms?
A: We receive L/C D/A D/P T/T Western Union MoneyGram
