60W POE injector with standard
- Категория: Ethernet & Communication Modules >>>
- Поставщик: Shenzhen,Hi-Net,Technology,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 2868.79 $* | 3011.24 $* |
| Aug-19-2025 | 2844.9 $* | 2986.39 $* |
| Jul-19-2025 | 2386.57 $* | 2505.63 $* |
| Jun-19-2025 | 2796.21 $* | 2936.64 $* |
| May-19-2025 | 2434.55 $* | 2556.41 $* |
| Apr-19-2025 | 2747.91 $* | 2884.45 $* |
| Mar-19-2025 | 2723.83 $* | 2859.17 $* |
| Feb-19-2025 | 2699.59 $* | 2834.10 $* |
| Jan-19-2025 | 2675.42 $* | 2809.46 $* |
Характеристики
Gigabit 60W POE injector with standard IEEE802.3bt
Description
The PE60 is a single port Mid spans offer a compact and cost effective, fully IEEE802.3bt compliant solution for remote powering of wireless LAN (WAN) access points, IP Security cameras, VoIP telephone and other low port density installations.
The PE30 PoE Mid-spans eliminate the need for external power supply and its associated AC/DC power cabling, providing a compact, affordable, safe and reliable power solution over existing Ethernet infrastructure.
Features
IEEE802.3, IEEE 802.3u, IEEE802.3ab, IEEE802.3af, IEEE802.3at, IEEE802.3bt.
Up to 60W of power on 4pairs.
Supports 10/100/1000 Base T applications
LED indicators power input and PoE output indication
Distance up to 100 meters
Internal AC/DC converter no need for external power brick
Easy plug and play installation
|
Description |
|
|
Interfaces |
1 x RJ-45 Connector for Data 1 x RJ-45 Connector for PoE out + Data |
|
Indicators |
PoE: Alt A, Alt B |
|
Standard |
IEEE802.3af, IEEE802.3at, IEEE802.3bt |
|
Power Method |
100-240VAC, 50/60Hz |
|
Output Voltage |
56VDC |
|
PoE Budget |
60W |
|
Output PoE Pin Assignment |
Alternative A: V+ (RJ45 Pin3,6), V- (RJ45 Pin 1,2) Alternative A : V+ (RJ45 Pin4,5), V- (RJ45 Pin 7,8) |
|
Dimensions |
180 x 65 x 40 mm |
|
Weight |
0.6kg |
|
Operating Temperature |
0 to 40℃ |
|
Storage Temperature |
-10 to 70℃ |
|
Operating Humidity |
5 to 95% Noncondensing |
|
Electromagnetic Emission & Immunity |
FCC (Part15, Class B) CE (EN55022/24) |
|
Safety Approvals |
CE/LVD (EN60950-1) |
|
Package List |
|
|
PoE Injector |
1pcs |
|
User Manual |
1pcs |
