Характеристики
HNOC liquide packaging machine price/small liquid packaging machine
Products Description
Standard Features
* Bag-making, sealing, packing, print date in one operation.
* English and Chinese screen display, operation is simple.
* PLC computer system, function is more stable, adjustment any parameters not need stop machine.
* It can stock ten dispose, simple to change variety.
* Double sever motors drawing film position accurately and the speed more fast.
* Temperature independent control system precision get to ± 1°C.
* Horizontal, vertical temperature control, suitable for various of mix film, PE film packing material.
* Packing type diversification, pillow sealing, standing type, punching etc.
* Work circuinstance quiet, low noise.
* English and Chinese screen display, operation is simple.
* PLC computer system, function is more stable, adjustment any parameters not need stop machine.
* It can stock ten dispose, simple to change variety.
* Double sever motors drawing film position accurately and the speed more fast.
* Temperature independent control system precision get to ± 1°C.
* Horizontal, vertical temperature control, suitable for various of mix film, PE film packing material.
* Packing type diversification, pillow sealing, standing type, punching etc.
* Work circuinstance quiet, low noise.
Working Process:
The working processes include: The machine pull laminate packaging film to the pouch forming devices, and go through the vertical sealing plate, in the meanwhile, the dosing device dose the product into the pouch, then will do the horizontal sealing and cutting off. Above is the typical working process diagram.
Product parameters
ITEM | HNOC-i420 |
Bag length | 60-300 mm(L) |
Bag width | 60-200 mm(W) |
Film width | 420 mm |
Packaging rate | 5-60 bags/min |
Mmeasuring range | 150-1200 ml |
Air consumption | 0.65 mpa |
Gas consumption | 0.3 m³/min |
Power voltage | 220 VAC/50Hz |
Power | 2.2 kw |
Dimension | (L)1080×(W)1300×(H)1400mm |
machine weight | 500 kg |
