1.SZG vacuum rotary dryer
2.Model:HZG
3.Pressure in tank:-0.01-0.15
4.Jack design pressure:less than 0.

SZG vacuum rotary dryer





Main Application:

HZG drum drier is used in the industry of pharmaceutical,foodstuff,feedstuff,and chemical to dry material,such as tablet,instant soluble medicine,instant soluble food,plastic,resin and eatable powder.

Feature:

Target material can be heat sensible,easily oxidized,fragile crystal,recycled soluble granules and poisoning material.

When the container rotates,heating point is continuously changes,so material dries rapidly and evenly.Indirect heating can prevent pollution and dead corner.It is easy to clean maintain and operate.The design ensures well sealed function.

Operating Principle:

Well sealed interlayer is designed for heat carriers,such as water and vapour.Heat is delivered to material through inner side.The container rotates slowly and material gets mixed and heated.Steam from the material releases in a vacuum room and pumps out to recycle so that material gets dry rapidly.

Nowadays, Jiangyin Haixiang Machinery Co.,ltd have customers both in China and abroad.Foreign customers such as Russian,East Europe,Middle East,South America,North America,East Asia,Southeast Asia, Africa,etc.















Model	100	350	500	750	1000	1500	2000	3500	4500
Tank volume	100	350	500	750	1000	1500	2000	3500	4500
Loading volume	less 50	less 175	less 250	less 375	less 500	less 750	less 1000	less 1750	less 2250
Rotating speed	3-13
Motor power(kw)	0.75	1.1	1.5	2100-2400	3	3	4	5.5	7.5
Floor space	2160×800	2260×800	2150×800	2560×100	2860×1300	3260×1400	3760×1800	3760×1800	3960×2000
Rotary height	1750	2100	2250	2490	2800	2940	2990	3490	4100
Design pressure inside tank	-0.01-0.15
Jacket design pressure	less than0.3
Working temperature(°C)	In tank less than				Jacket less than 140
Condensing vacuum pump	2X-15A	2X-30A	2X-30A	2X-30A	2X-70A	JZJX300	JZJX300	JZJX600	JZJX600
Vacuum, power	2KW	3KW	3KW	3KW	5.5KW	87KW	49.5KW	811KW	420.5KW
No Condensing Vacuum	SK-0.4	SK-0.8	SK-0.8	SK-2.7B	SK-2.7B	SK-3	SK-6	SK-6	SK-6
Pump models, power	1.5KW	2.2KW	2.2KW	4KW	4KW	5.5KW	11KW	11KW	11KW
Weight(kg)	800	1200	1200	1500	2800	3300	3600	6400	7500





the machine are made by the matericals  Stainless Steel



the above pic and details are just for your ref , if you are interested in it , pls contact me directly as the below information,I will show you more parameters of the machine.



we could customized the machine as your oder
