В ручном режиме от аккумулятора катушечная Обмотка Машина для литий-ионный аккумулятор

В ручном режиме от аккумулятора катушечная Обмотка Машина для литий-ионный аккумулятор

Категория: Оборудование для изготовления трансформаторов >>>
Поставщик: Xiamen,Tob,New,Energy,Technology,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-19-2025	0.96 $*	0.38 $*
Aug-19-2025	0.48 $*	0.48 $*
Jul-19-2025	0.48 $*	0.35 $*
Jun-19-2025	0.49 $*	0.7 $*
May-19-2025	0.1 $*	0.38 $*
Apr-19-2025	0.46 $*	0.78 $*
Mar-19-2025	0.15 $*	0.2 $*
Feb-19-2025	0.80 $*	0.63 $*
Jan-19-2025	0.36 $*	0.81 $*

Характеристики

Manual Coil Winding Machine For Li Ion Battery Making

Product Description

SPECIFICATION:

TOB-JR135-Cylinder semi-automatic winder machine is used for winding battery anode/cathode electrodes with separator together in the research of Li-ion cylinder batteries.

Model	Semi-Automatic Winding Machine TOB-JR135-C/ TOB-JR135-P
Working Voltage	AC110V/220V, 50/60HZ
Power	40W
Warranty	·One Year limited warranty with lifetime support
Winding Speed	0 - 170 RPM Adjustable
Suitable battery size	Less than Φ35*L90mm, or according to your requirement
Winding Mode	Switchable between clockwise and counterclockwise
Output	70-100EA/h, according to battery size and maunal
Product Dimensions (LWH)	550310270mm
Net weight	About 20kg (45 lbs)
Package size	720320280mm
Package weight	40kg
Application Notes	This machine can be used for cylinder battery with round winding shaft, and you can also choose the square winding shaft for pouch cell core winding, We will supply with the suitable winding accessories according to your battery model

PACKAGE LIST

Item	Qty
Semi-Automatic Winding Machine TOB-JR135-P	1 set
Power cord	1 pcs
Allen hex wrench	5 pcs
Foot plate	1 pcs
Round winding shaft or square winding shaft	1 set
