Контроллер постоянного тока для электромобиля 1000 Вт 48 В 60 72 в 40 А бесщеточный контроллер
- Категория: Motor Controller >>>
- Поставщик: Guangzhou,Idealplusing,Information,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.96 $* | 0.52 $* |
| Aug-15-2025 | 0.36 $* | 0.84 $* |
| Jul-15-2025 | 0.65 $* | 0.62 $* |
| Jun-15-2025 | 0.12 $* | 0.87 $* |
| May-15-2025 | 0.44 $* | 0.38 $* |
| Apr-15-2025 | 0.28 $* | 0.4 $* |
| Mar-15-2025 | 0.95 $* | 0.96 $* |
| Feb-15-2025 | 0.29 $* | 0.47 $* |
| Jan-15-2025 | 0.64 $* | 0.6 $* |
Характеристики
PRODUCT CHARACTERISTICS
1 | Silent |
2 | High efficiency |
3 | More than 24 months service time |
4 | High torque current |
5 | High performance aluminum |
6 | Heat dissipation |
7 | More channels for heat dissipation |
8 | IP55 waterproof |
9 | Apply for electric bicycles or electric motorbikes |
SPECIFICATION
Input voltage | 48VDC/60VDC/72VDC |
Output current | 40A |
Capacity | 1000W |
Efficiency | 93% |
Voltage stability | Less than 1% |
Load stability | Less than 1% |
Insulation resistance | Between output and input >50MQ2 |
Between input and casing >50MQ | |
Between output and casing >50MQ2 | |
Output protection #1 | temperature protection 95 C |
Output protection #2 | Over-current protection |
Output protection #3 | Short-circuit protection |
Output protection #4 | Over-voltage protection |
Storage temperature | -40~+60℃ |
Working temperature | -25~+55℃ |
Size | 178*86*46(MM) |
NW/GW | 0.5KG /1KG |
Mode list
NO | Input voltage | Output current | Output Power |
#1 | 36VDC/48VDC/60VDC | 17A | 350W |
#2 | 48VDC/60VDC/72VDC | 17A | 350W |
#3 | 36VDC/48VDC/60VDC | 27A | 500W |
#4 | 48VDC/60VDC/72VDC | 27A | 500W |
#5 | 48VDC/60VDC/72VDC | 32A | 800W |
#6 | 48VDC/60VDC/72VDC/84VDC/96VDC | 32A | 800W |
#7 | 48VDC/60VDC/72VDC | 40A | 1000W |
#8 | 48VDC/60VDC/72VDC/84VDC/96VDC | 40A | 1000W |
#9 | 48VDC/60VDC/72VDC | 50A | 1500W |
#10 | 48VDC/60VDC/72VDC/84VDC/96VDC | 50A | 1500W |
#11 | 48VDC/60VDC/72VDC | 60A | 2000W |
#12 | 48VDC/60VDC/72VDC/84VDC/96VDC | 60A | 2000W |
#13 | 48VDC/60VDC/72VDC | 80A | 3000W |
#14 | 72VDC/84VDC/96VDC/108VDC/120VDC | 80A | 3000W |
#15 | 48VDC/60VDC/72VDC | 100A | 5000W |
#16 | 72VDC/84VDC/96VDC/108VDC/120VDC | 100A | 5000W |
CONTROLLER DRAWING
FAQ
Q1. Can I have a sample order?
A: Yes, sample order is acceptable to test and check quality for the first cooperation
Q2. What about the lead time?
A: Most of the model in the stock, sample lead time after receive payment 1-3 working days
Q3. Do you have any MOQ limit?
A: Low MOQ, 5 pieces for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx, or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed with an order?
A: Initially, let us know your requirements or application. Besides, We quote according to your requirements or our suggestions. Thirdly, customers confirm the samples and places deposit for formal order. Finally, We arrange production.
Q6. Is it acceptable to print the buyer logo on the product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: How to deal with the flaw?
A: Our products are produced in a strict quality control system and the percent of pass is often maintained over 99.8%.
Q8: Do you offer a guarantee for the products?
A: Yes, we offer a 1-year warranty for all power supply.
