Product Description
4 Paths Film Applicator Four Side Wet Film Applicator/Multislot Coating Applicator for Film Coating Machine
Features
This is fixed thickness precision film applicator with four paths of 5μm,10μm,15μm and 20μm, which is designed for making thin film coating at small quantity.
1.LITH-DSP is designed for use on a flat substrate coating uniformity paint,adhesives and
similar products.Our company put more grooves precision coating
device diversity and alternative fixed groove coating device is incorporated in a meter.
2.Technical parameters:
2.1 Suitable for aqueous, acidic and alkaline products.
2.2 High grade stainless steel wear-resistant material
2.3 The effective coating width:
LITH-DSP206 Universal type → 80mm (coating device total length 100mm)
LITH-DSP205 lengthened type → 160mm (coating device total length 190mm)
Option 1: 80mm film applicator
- Made of stainless steel
- 100 mm length
- Coating width: 80 mm
- Coating thickness: 5μm,10μm,15μm,20μm one each side
- Customized length is available upon request
Option 2: 160mm film applicator
- Made of stainless steel
- 190 mm length
- Coating width: 160 mm
- Coating thickness: 25μm,50μm,75μm,100μm one each side
- Customized length is available upon request
Specification
Universal type | The effective coating width |
LITH-DSP206 | 80mm (coating device total length 100mm) |
LITH-DSP206/1 | (5µm,10µm,15µm,20µm) |
LITH-DSP206/2 | (25µm,50µm,75µm,100µm) |
LITH-DSP206/3 | (50µm,100µm,150µm,200µm) |
LITH-DSP206/4 | (30µm,60µm,90µm,120µm) |
Lengthened type | The effective coating width |
LITH-DSP205 | 160mm (coating device total length 190mm) |
LITH-DSP205/2 | (25µm,50µm,75µm,100µm) |
LITH-DSP205/3 | (50µm,100µm,150µm,200µm) |
LITH-DSP205/4 | (30µm,60µm,90µm,120µm) |
LITH-DSP205/5 | (100µm, 200µm,300µm,400µm) |
LITH-DSP205/6 | (50µm, 75µm,100µm,150µm) |
LITH-DSP205/7 | (100µm, 150µm,200µm,250µm) |
LITH-DSP205/8 | (250µm, 500µm,750µm,1000µm) |
