CHC I73 Высокая точность Gps Rtk De Doble Frecuencia измерительный инструмент i73/T5Pro GPS приемник GNSS
- Категория: Other Test Instruments >>>
- Поставщик: Chengdu,Zhicun,Space,Surveying,And,Mapping,Instrument,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 4789.50 $* | 5028.29 $* |
| Aug-15-2025 | 4748.71 $* | 4985.82 $* |
| Jul-15-2025 | 3984.1 $* | 4183.19 $* |
| Jun-15-2025 | 4668.94 $* | 4901.49 $* |
| May-15-2025 | 4064.28 $* | 4267.65 $* |
| Apr-15-2025 | 4587.2 $* | 4816.56 $* |
| Mar-15-2025 | 4547.87 $* | 4774.99 $* |
| Feb-15-2025 | 4507.65 $* | 4732.79 $* |
| Jan-15-2025 | 4467.55 $* | 4690.35 $* |
Характеристики
Products Description
Technical parameter
Mobile station | ||||
Channels | 624 channels | |||
GPS | L1, L2, L5 | |||
GLONASS | L1, L2 | |||
Galileo | E1, E5a, E5b | |||
BeiDou | B1, B2, B3 | |||
SBAS | L1 | |||
QZSS | L1, L2, L5 | |||
Real time kinematics (RTK) | Horizontal: 8 mm + 1 ppm RMS Vertical: 15 mm + 1 ppm RMS Initialization time: < 10 s Initialization reliability: > 99.9% | |||
Post -processing kinematics (PPK) | Horizontal: 3 mm + 1 ppm RMS Vertical: 5 mm + 1 ppm RMS | |||
Post - processing static | Horizontal: 2.5 mm + 0.5 ppm RMS Vertical: 5 mm + 0.5 ppm RMS | |||
Code differential | Horizontal: 0.4 m RMS Vertical: 0.8 m RMS | |||
Autonomous | Horizontal:1 m RMS Vertical: 1.5 m RMS | |||
Positioning rate | 1 Hz, 5 Hz and 10 Hz | |||
Time to first fix | Coldstart: < 45 s Hot start: < 30 s Signal re-acquisition: < 2 s | |||
RTK tilt - compensation | Additional horizontal pole-tilt uncertainty typically less than 10 mm +0.7 mm/°tilt | |||
Size (L x W x H) | 119mm x 119mm x 85mm (4.7 in × 4.7 in × 3.3 in) | |||
Weight | 0.73 kg (1.60 lb) | |||
Environment | Operating:-40°C to +65°C (-40°F to +149°F) Storage: -40°C to +85°C (-40°F to +185°F | |||
Humidity | 100% condensation | |||
Ingress protection | IP67 waterproof and dustproof, protected from temporary mmersion to depth 1m | |||
Shock | Survive a 2-meter pole drop | |||
Tilt sensor | Calibration-free IMU for pole -tilt compensation.Immune to magnetic disturbances. | |||
Front panel | 4 LED | |||
Certifications | FCC Part 15 (class B Device), FCC Part 22, 24, 90; CE Mark; NGS Antenna Calibration. | |||
Wi-Fi | 802.11 b/g/n, access point mode | |||
Bluetooth | BT4.1 | |||
Others | NFC | |||
Ports | 1 x USB Type-C port (data download， charging,firmware update) 1 x UHFantenna port (TNC female) | |||
UHFradio | RTCM 2.x, RTCM 3.x, CMR input / output HCN, HRC, RINEX 2.11, 3.02 NMEA 0183 output | |||
Data storage | 8 GBinternal memory | |||
Power consumption | 4 W (depending on user settings) | |||
Li-ion battery capacity | Built-in non-removable battery 6800 mAh, 7.4V | |||
Operating time on internal battery | RTK:Rover 12 h Static:up to 15 h | |||
model | HCE320 | |||
network | 4G All Netcom (Mobile Unicom Telecom 2G/3G/4G) | |||
operating system | Android 7.1 | |||
CPU | Eight core speed processor | |||
RAM+ROM | 2GB+16GB | |||
LCD panel | 5.5-inch AMOLED self-illuminating display | |||
Physical buttons | Full function button | |||
input method | Hua ce Independent input method | |||
battery | 8000mAh | |||
Three Preventions | IP68 | |||
Stylus | yes | |||
iBase | ||||
Satellite tracking | GPS+BDS+Glonass+Galileo, supporting the third generation of Beidou | |||
operating system | Linux system | |||
Initialization time | ＜5s (typical value) | |||
Initialization reliability | >99.99% | |||
Receiver appearance | button | 1 dynamic/static switch button, 1 power button | ||
Indicator light | 1 differential signal light, 1 satellite light | |||
Display screen | 1 LCD display | |||
Static accuracy | Plane accuracy: ±(2.5+ 0.5×10-6×D) mm Height accuracy: ±(5+0.5×10-6×D) mm | |||
RTK accuracy | Plane accuracy: ±(8 + 1×10-6×D) mmHeight accuracy: ±(15+ 1×10-6×D) mm | |||
Single machine accuracy | 1.5m | |||
Code difference accuracy | Plane accuracy: ±(0.25+ 1×10-6×D) mmHeight accuracy: ±(0.5+ 1×10-6×D) mm | |||
Electrification parameters | battery | Removable 14000mAh lithium battery, supports 12+ hours battery life of base station | ||
External power supply | The host can be powered by DC power supply, 220V AC power supply, and can directly power the host through the radio (9-24) V DC | |||
Physical properties | size | Φ160.54 mm*103 mm | ||
weight | 1.73kg | |||
Material | Magnesium alloy AZ91D body | |||
Waterproof and dustproof | IP68 | |||
Receiver function | Super dual-shot, one-key start, base station offset warning, base station battery reminder | |||
