Медная трубка 110 В/220/380 воды Нагревательный элемент withDN32/1 2 дюйма медная нить для термостат водонагреватель
- Категория: Heating Equipment >>>
- Поставщик: Shenzhen,Lujinxun,Electric,Heating,Appliance,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.91 $* | 0.27 $* |
| Aug-16-2025 | 0.88 $* | 0.7 $* |
| Jul-16-2025 | 0.73 $* | 0.99 $* |
| Jun-16-2025 | 0.69 $* | 0.22 $* |
| May-16-2025 | 0.68 $* | 0.41 $* |
| Apr-16-2025 | 0.86 $* | 0.22 $* |
| Mar-16-2025 | 0.13 $* | 0.96 $* |
| Feb-16-2025 | 0.31 $* | 0.92 $* |
| Jan-16-2025 | 0.63 $* | 0.81 $* |
Характеристики
Copper Tube 110V/220/380 Water Heating Element withDN32/1.2inch Copper Thread for Thermostat Water Heater 3KW/4.5KW/6KW/9KW/12KW
Size in Stock
The 5 sizes we show are in stock, which can be sent out in 1-4days. Other specificaction can customized. Contact with us freely.
| Tube Length | Tube Diameter | Thread Size | Voltage | Power | Material |
| 190mm | 8mm | DN32 (1 1/4") | 220V/380V | 3KW | Copper |
| 210mm | 8mm | DN32 (1 1/4") | 220V/380V | 4.5KW | Copper |
| 250mm | 8mm | DN32 (1 1/4") | 220V/380V | 6KW | Copper |
| 290mm | 8mm | DN32 (1 1/4") | 220V/380V | 9KW | Copper |
| 355mm | 8mm | DN32 (1 1/4") | 220V/380V | 12KW | Copper |
Technology
| Heat intensity | Not exceeding 30w/cm2 (advisable) |
| Exhaust extreme (when cold) | <=0.1mA to 242 v. |
| Insulation (when cold) | 5 Min Ohms 500 Watts minimum |
| Power | Depends on the dimension |
| Dielectric strength | 1500v. 1/sec |
| Working temperature | 650 Deg C max. |
| Length tolerance | +/-1.5% |
| Diameter tolerance | -0.02 to -0.06 mm |
| Cut off connection tolerance | +/-15 mm |
| Power tolerance (w) | +5 % - 10 % |
| Cold areas | Depends on length and diameter 5-25mm |
