Характеристики
China hot sale memory card making machine Jinan 10w/20w fiber laser marking machine
Product Description
Fiber laser marker - Laser Markers, available in two different power levels, the 10W Model F10 , the 20W Model F20. 30W Model F30 .The laser deliver a high power beam directly to the marking surface via flexible fiber cable than mark character , digital , date codes , barcode , logo etc .
memory card making machine
The samples :
Specification(Fiber)
MACHINE MODEL | F10 | F20 | F30 |
LASER POWER | 10W | 20W | 30W |
LASER WAVELENGTH | 1064nm | 1064nm | 1064nm |
FIBER LENGTH | 2.5m | 2.5m | 2.5m |
LASER UNIT USING LIFE | 100,000 hours | 100,000 hours | 100,000 hours |
MARKING SPEED | <= 7000mm/s Character marking speed and production line speed depend on material , character size and desired marking quality | ||
MARKING SPEED | 2-3 digital(2*3mm)/ 0.01s | 3-5 digital(2*3mm)/ 0.01s | 5-8 digital(2*3mm)/ 0.01s |
MARKING DEEPTH | 0.01-0.2MM | 0.01-0.2MM | 0.01-0.5mm |
MIN. LINE WIDTH | 0.01MM | 0.01MM | 0.01MM |
MIN. CHARACTER HEIGHT | 0.2MM | 0.2MM | 0.2MM |
MARKING FILED | (110*110mm (focal length f=160mm)
| (110*110mm (focal length f=160mm) Optional 175mm lens
| (110*110mm (focal length f=160mm) Optional 175mm lens , 250mm lens
|
POWER SUPPLY | 220V 50HZ / 2A | 220V 50HZ/2A | 220V 50HZ/2A |
POWER CONSUMPTION | 300 W/ hours | 800W/ HOUR | 1000W/HOUR |
COOLING | AIR | AIR | AIR |
POSITIONING | Visible red power | Visible red power | Visible red power |
OPERTAION TEMPERATURE | 25℃ to 28℃ | 25℃ to 28℃ | 25℃ to 28℃ |
HUMIDITY | 5% to 75% (no condensation) | 5% to 75% (no condensation) | 5% to 75% (no condensation) |
Packaging & Shipping
1.Standard Ply-wooden case for exporting, non fumigation
2.Express and transport (or by customers' demand)
3. 5~7 working days after payment received
Company Information
Looking for agents all over the world~~~~
