Products Description

Compatible Wireless Indoor single direction Wifi signal repeater booster amplifier

TX-MA2 It is specially developed for the 1.5GHz frequency band according to the wireless broadcasting standard, and can match most frequency extending technology such as DSSS, OFDM, etc.
It can max the wireless signal extending range at the same signal speed.
TXtelsig designs and produces the signal jamming and wireless coverage product.

Application
1.1.4G wireless WLAN access point or client side
2.Navigation system based on 1.5GHz
3.IOT data transferring based on 1.5GHz
1.4GHZ drone remote control and photo transmission

Attention
1.Power supply needs 12V/5A or >60W
2.If the output power is ≥5W, then better heat-dissipation is neccessary such as adding a cooling fan or fin
3.The power should be turned on after the Antennas are connected with the front signal source device
Specification
Working Frequency
1.55~1.62GHz
Working Voltage
8-24V (Default 12V)
Gain
5-34dB (Default30dB)
Reflection coefficient
≤-15dB
Input Power
≤13dBm
Max Output Power (P1dB)
20W(43dBm)
EVM
5%38dBm 802.11g 54Mbps OFDM 64QAM BW 20MHz(1.57G channel)
Working Current
1800mA@Pout 38dBm 12V
Working Temperature
-20℃~60℃
73.52941176
117.6470588
Outshell Size
132*53*17mm
RF interface
Input interface--male joint SMA ;
Output interface--male joint SMA with internal needle
Power Supply Port
6.0*2.0mm DC joint
Outshell Material
Oxidation and Sand Blast Aluminum
Fixed Holes
4 holes around the outshell
Net Weight
0.190kgs
