CH3-10Q/150 12KV эпоксидной смолы изолятор контактный ящик для высокого напряжения распределительное
- Категория: Electrical Contacts and Contact Materials >>>
- Поставщик: Yueqing,Weisen,Electric,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 12.70 $* | 13.74 $* |
| Aug-16-2025 | 12.2 $* | 13.18 $* |
| Jul-16-2025 | 10.81 $* | 11.63 $* |
| Jun-16-2025 | 12.1 $* | 13.75 $* |
| May-16-2025 | 10.77 $* | 11.64 $* |
| Apr-16-2025 | 11.29 $* | 12.77 $* |
| Mar-16-2025 | 11.38 $* | 12.11 $* |
| Feb-16-2025 | 11.12 $* | 12.49 $* |
| Jan-16-2025 | 11.74 $* | 12.87 $* |
Характеристики
Product Description
Product Name | 12KV Switchgear Epoxy Resin Contact Box Insulator CH3-10Q/150 |
Material | Red Epoxy Resin |
Function | For insulation in high voltage switchgear |
Package | Standard exporting packing |
Product performance description
产品性能介绍说明
CH3-10Q/150 630~1250A
The contact box adopt technique of epoxy resin automatic pressure gelatin(APG). It mainly used in 12kV or 10 kV High Voltage switchgear and take the role of insulation function for the VCB contact.
Rated insulating level: 1 Min power frequence withstand 42kV, Rated lightning impulse withstand voltage 75kV
Manufacturing Technique
Details Images
Application
Usage: High Voltage Switchgear
Material:Epoxy Resin
Specification: CH3-10Q/150 series
Material:Epoxy Resin
Specification: CH3-10Q/150 series
Operating Condition
1.Altitude:≤1000m
2. Ambient temperature:+40°C~10°C
3. The relative humidity should not be more than 95%at+20°C ambient temperature
2. Ambient temperature:+40°C~10°C
3. The relative humidity should not be more than 95%at+20°C ambient temperature
Packing&Shipping
Packaging Details: Standard exporting packing
Delivery Port: Shanghai or Ningbo
Company Introduction
Located in Yueqing, Zhejiang, Yueqing Weisen Electric Co., Ltd is a professional manufacturer of low voltage and high voltage switchgear and vacuum circuit breaker insulating accessories. We have perfect organization structure and associated functional department. As we have cooperated with foreign customers for decades, our business systerm is quite perfect which based on common interest.
Yueqing Weisen Electric Co., Ltd. is a professional power equipment manufacturer integrating research, development, production and sales. Since the company's products were shown in the market, it has won the praise of the majority of users with its superior performance, advanced technology, exquisite technology, reliable quality and high-quality service. The products have been sold in 29 provinces, cities and autonomous regions.
Our Services & Strength
We can design for you according to customers' requirements.
