Переключатель термостата KSD301 250 в 16 А саморегулирующийся терминал кондиционирования воздуха
- Категория: Home Appliance Parts >>>
- Поставщик: Wuhan,Zhenguan,Industry,And,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.1 $* | 0.73 $* |
| Aug-16-2025 | 0.60 $* | 0.5 $* |
| Jul-16-2025 | 0.84 $* | 0.31 $* |
| Jun-16-2025 | 0.71 $* | 0.75 $* |
| May-16-2025 | 0.55 $* | 0.83 $* |
| Apr-16-2025 | 0.93 $* | 0.40 $* |
| Mar-16-2025 | 0.34 $* | 0.14 $* |
| Feb-16-2025 | 0.66 $* | 0.99 $* |
| Jan-16-2025 | 0.29 $* | 0.80 $* |
Характеристики
KSD301 250V 16A Thermostat Switch Self-control Air Conditioning Termostato Bimetal Overload
Product Description
1,electrical parameters: 10/250V (resistance loaded),
2,temperature range: 40 ~ 250C
3,service life: 10/250V 10000 cycle,
4,contact resistance than 50m Ω; :
5,insulation resistance: > Ω 100M
product drawing
Performance data
| Electric rated | Operation temp | Contact type | Circuit resistance | Operation life |
16A 250V 15A 125V 10A 250V | 40-250℃ | A,B,M | <=50mOhm | 100000@10A 250V |
A=Contact opens when temperature rises to set point(NORMAL CLOSED)
B=Contact closes when temperature rises to set point(NORMAL OPEN)
M=Manual reset
