Competitive Advantage high quality industrial drier for sand,air dryer for sale



Brief Introduction



Reliable Supplier of silica dryer/alfalfa dryer/gold mine dryer is the ideal drying equipments to dry a variety of powdery,granulous,massive material with humidity such as river sand,silica sand,limestone,slag,coal ash,

sawdust,wood shavings,wood chips, chicken manure,cassava residue,coal slurry,etc in the industries of mineral dressing,building material,metallurgy, chemical and fertilizer.





Feature





1.High drying rate.The drying rate can reach 97%

.

2.Three different kinds of heating method.Coal heating,gas or LPG heating and diesal heating.



3.Lifting plate have angle distribution and perfect design, reliable performance so heat rate utilization is high, uniform drying, fewer cleaning materials.





Technical data



Type	Gradient(%)	Speed(r/min)	Inlet air temperature(°C)	Power(KW)	Production(t/h)	Weight(t)
600*6000	3-5	3-8	max 700	3	0.5-1.5	2.9
800*8000	3-5	3-8	max 700	4	0.8-2	3.5
800*10000	3-5	3-8	max 700	4	0.8-2.5	4.5
1000*10000	3-5	3-8	max 700	5.5	1-3.5	5.6
1200*10000	3-5	3-8	max 700	7.5	1.8-5	14.5
1200*12000	3-5	3-8	max 700	11	2-6	14.8
1500*12000	3-5	2-6	max 700	15	3.5-9	17.8
1800*12000	3-5	2-6	max 700	18	5-12	25
2200*12000	3-5	15-6	max 700	18.5	6-15	33
2200*18000	3-5	15-6	max 700	22	10-18	53.8
2200*20000	3-5	15-6	max 700	30	12-20	56
2400*20000	3-5	15-5	max 700	37	18-30	60
3000*20000	3-5	15-5	max 700	55	25-35	78
3000*25000	3-5	15-5	max 700	75	32-40	104.9



Video:



https://www.youtube.com/watch?v=_UblZ7h1GcE#action=share







Installation Site







Workshop





After-Sales Service



1.We guarantee that the goods are made of the best materials and of first class workmanship,brand new,and comply in all respects with the quality and specifications and performance as stipulated in this Contract.



2.We guarantee that the goods,when correctly mounted and properly operated and maintained,shall give satisfactory performance for a period of 12 months after acceptance protocol's signature.



3.The warranty foresees the supply,free of charge,of the parts of the machine that get broken due to manufacturing defects.
