Керамическая волоконная плита HONGDA 1800 градусов цена огнестойкая


Поделиться:


Цена:12,00 $ - 296,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-18-2025 14.78 $* 15.92 $*
Aug-18-2025 14.17 $* 15.5 $*
Jul-18-2025 12.60 $* 13.71 $*
Jun-18-2025 14.98 $* 15.21 $*
May-18-2025 12.36 $* 13.16 $*
Apr-18-2025 14.96 $* 15.35 $*
Mar-18-2025 14.95 $* 15.41 $*
Feb-18-2025 13.1 $* 14.18 $*
Jan-18-2025 13.79 $* 14.99 $*

Характеристики


HONGDA 1800 degree ceramic fiber plate price flameproof heat insulation board



Product Description


 Heat insulation materials 1450c ceramic fiber board for furnace lining


Heat insulation materials 1450c ceramic fiber board for furnace lining





 What is Ceramic Fiber Board? factory price                               electromagnetic wave insulation material


flameproof heat insulation board provide a rigid solution for ceramic fiber insulation. The boards are manufactured through a wet forming process using alumina-silica fibers and binders. Standard board grades are standard, high purity, and zirconia. Boards are available in a variety of temperature ratings, dimensions, and custom vacuum formed shapes. If you are looking for a board not listed or a custom fabrication, please contact us directly.


 Heat insulation materials 1450c ceramic fiber board for furnace lining


flameproof heat insulation board is the best solution for your high temperature insulation. The mixture of refractory fibers and binders, which have low organic content is vacuum processed into high temperature ceramic fiber board that imparts good mechanical strength even after heating. Ceramic Board is a refractory board which has low thermal conductivity and high tensile strength and excellent resistance against thermal shock and chemical attack. Upon initial use at specific temperature the organic binder burns and turns the board to brownish giving slight odor. Once the binder is burnt out it will be pure white and odorless. factory price                               electromagnetic wave insulation material


































































































Ceramic Fiber Board


TypeStandardHigh AluminiumZircon

Classification temperature (°C)


 1260 1360 1430
Working Temperature (°C)1050  1200 1350
ColorPure white Pure white Pure white
Density (kg/m3)250-400250-400 250-400
Shrinkage on heating (%) (24hours,density as 128/m3)-3 (1000°C) -3 (1200°C) -3 (1350°C)

Thermal conductivity of various


temperatures (w/m.k)


(1000°C) (1000°C) (1000°C)

Compressive strength (Mpa)


 0.5 0.5 0.5
Chemical composition (%)AL2O3 46 52-55 39-40
 AL2O3+SiO2 97 99 -
 AL2O3+SiO2+ ZrO2 - - 99
 ZrO2 - - 15-17
 Fe2O3 <1.0 0.2 0.2
 Na2O+k2O ≤0.5 0.2 0.2

Dimensions (mm)



Common Specifications:


600*400*50


900*600*50


1200*600*50


support customize



This is only part of flameproof heat insulation board parameter, and there are detailed requirements to inform me so that We can provide detailed parameters for you.

Notes:Custom Specification parameters are available according to your actual requirements.





Packaging & Shipping


 Heat insulation materials 1450c ceramic fiber board for furnace lining





Heat insulation materials 1450c ceramic fiber board for furnace lining


Shipping and Packing of flameproof heat insulation board


1. Our packaging is as per customer's request.


2. Normal goods delivered by sea transport.


3. Sample shipping by express.





Productive Process

Heat insulation materials 1450c ceramic fiber board for furnace lining

Traditional production process is vacuum forming technique.Use blown ceramic fiber as the raw material , add a certain percentage of binding agent, packing grade additives and fully scatter into a mud pool. Throw it into the forming pool by pump, and stir by compressed air. Put the mold into forming pool, and make the fiber pulp be absorbed on the mould by the principle of vacuuming. Control the time of adsorption ccurately, let fiber wet material get vacuum dehydration , and place it in the tray for drying oven drying 10 to 24 hours. After drying of fiberboard through special grinding machine, trimming machine, control the size. factory price                               electromagnetic wave insulation material


Heat insulation materials 1450c ceramic fiber board for furnace lining


Hongda uses automatic production process. Compared with traditional production process,Hongda ceramif fiber board has obvious advantages: flameproof heat insulation board have a higher stability,better flatness, and more accurate size than ceramic fiber boards producted by traditional prodution process. Further more,Hongda use automatic temperature drying line,more quickly and deeply. It completes a deep drying by 2 hours,and drying uniformly,good quality,compared with the ceramic fiber boards have the same density by traditional production process,compressive strength and flexural strength are 5% higher.





Customer visiting


Heat insulation materials 1450c ceramic fiber board for furnace lining


With the company healthy and fast development, our products had been sold to all over the country, as far as Vietnam, India, Pakistan, Kazakhstan and other southeast Asian countries and regions.


GONGYI HONGDA FURNACE CHARGE CO.,LTD  enterprise tente is: "quality first, reputation first, customer first: it is our aim. "Scientific management, strong technical force, perfect testing means, advanced technological equipment and stable product quality are the guarantee of quality service.





Customer Reviews


 Heat insulation materials 1450c ceramic fiber board for furnace lining





Application

Ceramic fiber board refractory wood stove shaped 1800 ceramic fiber board

flameproof heat insulation board is manufactured in various densities, temperature grades, widths & lengths. This is ideal for use in Wood Stove, Fireplaces, Pizza Ovens, Kilns, Forges, Internal Baffle of Wood Stove, Pellet Stove, Backup Insulation of Refractory Bricks and Castable Linings, Furnace Hot Face Linings and Boiler Wall Insulation, heat shields, combustion chambers and fire protection.





Company Information


 Heat insulation materials 1450c ceramic fiber board for furnace lining


factory


Gongyi Hongda Furnace Charge Co., Ltd. is a comprehensive refractory enterprise integrating r&d, production and trade. The company mainly produces castable, ramming materials, plastic and other unshaped refractory materials, fired bricks and insulation materials. Products are widely used in steel, nonferrous metals, building materials and power industry. factory price                               electromagnetic wave insulation material


Hongda company has two produtction lines for refractory castables and respective production lines for shaped refractories, plastic refractory, three production lines for thermal insulation products. With annual capacity of 15000 tons of various castables, 30000 tons of shaped precast products, and 10000 tons of moldable refractory, therma.





certification


All our products, quality and quantity, delivery on time, delivery at the same time according to the needs of professional staff can be sent to you to work and coordinate the use of matters, after the construction of the operation of the materials to track the service.





TEAM


Hongda has a technical service team of more than 300 people, and has developed more than 80 patent products.The company can undertake projects from designing to development of new products in accordance with construction conditions and customers' specific requirements  factory price                               electromagnetic wave insulation material
