Стальная машина для полировки квадратных труб для алюминиевых труб
US $46000-$50000
Многофункциональная Автоматическая полировальная шлифовальная машина для металла камня
- Категория: Станок для полировки металла >>>
- Поставщик: Shanghai,Lima,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.94 $* | 0.83 $* |
| Aug-18-2025 | 0.14 $* | 0.15 $* |
| Jul-18-2025 | 0.21 $* | 0.78 $* |
| Jun-18-2025 | 0.61 $* | 0.50 $* |
| May-18-2025 | 0.31 $* | 0.60 $* |
| Apr-18-2025 | 0.0 $* | 0.58 $* |
| Mar-18-2025 | 0.27 $* | 0.1 $* |
| Feb-18-2025 | 0.49 $* | 0.20 $* |
| Jan-18-2025 | 0.30 $* | 0.79 $* |
Характеристики
Product Description
Application:
Electric power parts industry, automobile precision parts, non-metallic insulating board, friction materials, precision sheet metal manufacturing, rail transit equipment manufacturing, aerospace, nuclear power and other special materials processing, engineering, agricultural machinery medium plate processing, medical appliances, hardware tools, photovoltaic materials.
Metal surface treatment technology, for thin panel, thick panel, grinding, deburring, slagging, trimming.
Detailed Images
Maximum working width(mm) | 600 |
Minimum working length(mm) | 240 |
Dust extraction capacity(m3/h) | 4000 |
abrasive belt(mm) | 1030x1900 |
Feed speed(m/min) | 2-11 |
Total motor power(kw) | 12.46 |
Machine size(mm) | 1650x1700x1850 |
1.Faults Display fitted (sanding paper right and left deviation, inadequate air pressure, emergency knob, over thickness work piece). It’s easy to judge basic equipment trouble. Faults emergency stop adopts automatically descend protection facility, the
panel surface won’t be damaged from emergency stop.
2.Use branded conveyor, grinding duration is 3-5 times as ordinary conveyor.
3.Conveyor speed adjusted by stepless speed control (frequency controller is optional), easy adjusting. It can be adjusted as per
the work piece in processing to improve sanding quality.
4.Conveyor use marble material, its shape won’t be changed because of temperature.
Precision and grinding duration is higher than steel conveyor.
5.The safety device: On the control panel has an emergency stop button (latching), left and right side in the sand shelf
containing two photoelectric switch; relay pressure in low pressure pneumatic system operation, equipped with disc brakes on the
motor pulley to parking brake to ensure rapid emergency occurs.
6.The unique suction device, so that a better cleaning effect.
panel surface won’t be damaged from emergency stop.
2.Use branded conveyor, grinding duration is 3-5 times as ordinary conveyor.
3.Conveyor speed adjusted by stepless speed control (frequency controller is optional), easy adjusting. It can be adjusted as per
the work piece in processing to improve sanding quality.
4.Conveyor use marble material, its shape won’t be changed because of temperature.
Precision and grinding duration is higher than steel conveyor.
5.The safety device: On the control panel has an emergency stop button (latching), left and right side in the sand shelf
containing two photoelectric switch; relay pressure in low pressure pneumatic system operation, equipped with disc brakes on the
motor pulley to parking brake to ensure rapid emergency occurs.
6.The unique suction device, so that a better cleaning effect.
Related Products
Packing&Shipping
Company Introduction
FAQ
1.Delivery and Package:
We will take care of your machinery packages well like picture show.
·Our workers will make sure your machine clean before package.
·We will add stretchy film for the whole machine and spare parts for delicate protection.
·We will make export standard strong Wooden box case package as your request.
2.Guarantee:
The machine is guaranteed for 12 months .Within 12 months under normal using and maintenance, if the machine has something problem
,you will get spare part for free . more than 12 months,you will get the cost price for accessories. You will also get technical
support and service all the time.
3. Technical support:
·Technical support by Phone, Email ,Wechat, WhatsApp and Skype,24 hours online.
·We provide English version manual.
·Engineer available to service machinery overseas.
4. After sales services:
Our machine is installed and tested well before delivery. You can operation the machine immediately after received machine.
We will take care of your machinery packages well like picture show.
·Our workers will make sure your machine clean before package.
·We will add stretchy film for the whole machine and spare parts for delicate protection.
·We will make export standard strong Wooden box case package as your request.
2.Guarantee:
The machine is guaranteed for 12 months .Within 12 months under normal using and maintenance, if the machine has something problem
,you will get spare part for free . more than 12 months,you will get the cost price for accessories. You will also get technical
support and service all the time.
3. Technical support:
·Technical support by Phone, Email ,Wechat, WhatsApp and Skype,24 hours online.
·We provide English version manual.
·Engineer available to service machinery overseas.
4. After sales services:
Our machine is installed and tested well before delivery. You can operation the machine immediately after received machine.
