Цена по прейскуранту завода-изготовителя солнечная энергия инвертор с MPPT регулятором заряда 3 фазы 10kw Гибридный
- Категория: Solar Inverter >>>
- Поставщик: Foshan,Snat,Energy,Electrical,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 2975.20 $* | 3124.10 $* |
| Aug-15-2025 | 2950.25 $* | 3098.85 $* |
| Jul-15-2025 | 2475.60 $* | 2599.95 $* |
| Jun-15-2025 | 2900.21 $* | 3045.24 $* |
| May-15-2025 | 2525.6 $* | 2651.68 $* |
| Apr-15-2025 | 2850.42 $* | 2993.98 $* |
| Mar-15-2025 | 2825.92 $* | 2966.95 $* |
| Feb-15-2025 | 2800.99 $* | 2940.10 $* |
| Jan-15-2025 | 2775.24 $* | 2914.57 $* |
Характеристики
Model | NKG-10KW | NKG-15KW | ||
Rate Power | 10KW | 15KW | ||
Battery | Battery Voltage | 96VDC | ||
Low power shutdown voltage | 86VDC | |||
MPPT controller | Controller Types | With maximum power point tracking (MPPT) function controller | ||
Rate Current | 50A / 100A | |||
Current Limiting Protection | 52A / 102A | |||
Rate Voltage | 96VDC | |||
System Identification Voltage Range | DC72V-DC120V | |||
Operating Voltage Range | DC130V-DC180V | |||
charge mode | Three stages: constant current (quick charge), constant pressure, floating charge | |||
Battery Type | Sealed lead-acid battery, colloidal lead-acid battery, open lead-acid battery (you can customize parameters to charge other types of batteries) | |||
PV module input power | 5.3KW(50A) / 10.6KW(100A) | |||
Vmax-pv | ＜235VDC | |||
Vlow-pv | 120VC | |||
Vstar-pv | 130VC | |||
Vovet-pv | 230VDC | |||
Floating Charge Voltage (Lead Acid Battery) | 110.4V(Can be customized) | |||
Average charging Voltage (Lead Acid Battery) | 116.0V(Can be customized) | |||
PV module utilization | ≤99.97% | |||
Machine Efficiency | ≥96.5% | |||
Output Regulation Accuracy | ≤±1.5% | |||
emperature Coefficient | ±0.02%/℃ | |||
Temperature Compensation | 14.2V-(Maximum Temperature -25C)*0.3 | |||
Protective function | Input and output over-voltage protection, anti-reverse protection, short circuit protection, etc. | |||
inverter | Input phase number | Three-phase+N+G | ||
Input voltage | AC380VAC±15% | |||
Input frequency | 50Hz/60Hz±5% | |||
output voltage | AC220V/AC380V±2%（Steady state load） | |||
output frequency | 50Hz/60Hz±5%(main supply) 50Hz±0.1%（Battery powered） | |||
efficiency | ≥90%（100% resistive load） | |||
Output waveform | Pure sine wave | |||
Total harmonic distortion | Linear load＜3% Nonlinear load＜5% | |||
Dynamic load voltage transient | ＜±5%（ 0-100% ） | |||
Instantaneous recovery time | ＜10ms | |||
Battery and mains switching time | 1S-3S | |||
Unbalanced voltage | ＜±3% （Balancing load voltage） | |||
Overload capacity | 120% 20s； > 150%，100ms | |||
Other | operating ambient temperature | -10~40℃ | ||
relative humidity | 0～90% (No Condensation) | |||
Noise | 40-50dB | |||
structure | Product Size : D×W×H(mm) | 635*566*1295 | ||
Package size: D×W×H(mm) | 760*690*1540 | |||
Weight (Kg) | 180 | 210 | ||
