Машина для производства гранул корма домашней птицы 500 кг продажи в Замбии по низкой

Introduction for poultry feed pellet machine 500kg for sale

Feed machine for chicken is feed pellet maker to pelletize the solid grains crushed such as

corn, soybean meal, rice husk and straw, grass into the feed pellet for poultry and livestock feed mill.

Ring die pelletizer is the key machine among the animal feed pellet production line, its performance

to a great extent determines the final feed capacity playing a very important role in the feed processing.

Our engineers designed a HKJ 250 feed pellet maker after more than 13 --year professional research

and investigation with the feed pellet machine at home and abroad, which is of simple design structure,

easy operation for customers and reliable performance for small feed mill and farm for poultry,livestock

and fish.Our HKJ 250 feed pellet making machine can produce 500-1000 kg per hour feed ranging

from 2 to 8 mm diameter .

You can easily change the ring die to control the feed pellet diameter for differet animal and one-three

conditioners can be chosen for improve the feed quality for good taste and safety and reduce the machine

wear to prolong the machine serive life time.

Main Model for poultry feed pellet machine 500kg for sale

Advantege for poultry feed pellet machine 500kg for sale

1.Belt driven .large drive torque,stable operation and low noise.

2. Ring die uses the quick release hoop  type, easy to change with high efficiency and large output.

3.Ring die holes opening area has increased by 25% to achieve the best area-power ratio.

4.Different types of conditioner and feeder can be equipped based on requests.

5.Novel and compact structure,low noise,easy to operate and maintain,stable and safe in use.

Main Structure for poultry feed pellet machine 500kg for sale

China ring die animal feed pellet mill  for sale is made of Feeder,conditioner,pelletizing chamber

and motor and gear driven device

1.Feeder: to evenly convey the raw material into the conditioner, its flow rate can be controlled and

adjusted by the variable frequency motor.

2.Conditioner: to add the miosture into the raw material for mixing with the following advantages

2.1 starch gelatinization to improve feed pellet digestibility.

2.2 good liqudity to increse raw mateail adhesiveness for feed pellet forming rate.

2.3 the soften raw material can lubricate and reduce the abrasion between ring die and roller ,meanwhile

      lowe the hear from rubbing to save electric energy, finally make themselves quick go through the rind die

      holes to weaken the machine working pressure.

2.4 improve the feed machine hourly capacity.

2.5 the suitable steam consumption can increase the density and reduce powder rate to get prime quality feed pellet.

2.6 extend the ring die and roller life serive.

2.7 more lessen the electricity consumption to save the production cost.

3. Pelletizing chamber: mainly contain rind die and rollers

3.1 Ring Die: Made of high quality alloy steel with good abrasion resistance, strong breaking capacity and

      good corrosion resistance, the surface hardness of the rind die can be up to HRC 53 to 59 processed

      by forging, turning, polishing and nitriding treatment.
3.2 Die Holes: straight hole type, feeding orifice should be bigger than the die aperture to facilitate raw

      material into the die.
3.3 Aperture ratio: in order to improve the production output , it will choose the appropriate opening rate

     according to the aperture size, generally speaking it will be chosen between 20-30%.
3.4 Ring die thickness: it relates to the aperture and material characteristics, for different raw material, it

      needs to adopt the best thickness and aperture ratio in order to obtain high quality pellet feed.

3.5 Roller: generally made of high carbon alloy steel and its hardness is higher than or equal to the ring

      die hardness.In order to enhance their ability for grabbing,the roller surface is full of grooves along the

      axial direction to increase friction and reduce wear resistance.
3.6 Clearance between rind and roller: if gap is too smaller, it will increase mechanical abrasion between

      ring die and roller ;If gap is too big, raw material is easy to slip between the ring die and roller to affect

      raw material extrusion and worsen feed quality.General clearance is about 0.1 to 0.4 mm.

Working principle for poultry feed pellet machine 500kg for sale

The raw material is forced into the pelletzing chamber and evenly distributed the raw material between

the ring die and roller by spreader.Ring die rotates driven by the motor, then to use the the friction from

raw material and to make the rollers produce autoroatation but not revolution.
By the function of rotation between rind die and roller, the raw material is to be grabbed and squeezed

into the aperture, finally forming columnar feed pellet, the cutters outside the ring die can cut the long feed

pellets into small with certain length as the customer need.

Single Pellet Machine Wooden Box Package,Production Line Load By Container:

Listed Company Information:

Shandong Double Crane Machinery Manufacture Co.,Ltd. is located in economical and technological

development zone, Leling city,Shandong province,very close to the expressway from Beijing to Shanghai.

Our company is the high and new technological enterprise dedicated to manufacture feed pellet machines and

biomass pellet machines to worldwide users.

Sticking to the product developing ideas of simplicity,perfection,quality and innovation,we have been always focused

on designing and manufacturing feed pellet machines and biomass pellet machines since the foundation in 2005.

We had cooperated with domestic famous universities like Shandong University,Jinan University and Shandong

Agricultural University in feed pellet production line and biomass pellet production line research and development

since 2008.We had obtained more than 30 patents and successfully developed 8 series of products,including 60

different kinds of machines.

In the feed pellet industry ,we had achieved advanced level in man-machine design,functional design,automatic

control and user experience and became the professional pellet mill manufacturer in China.We have strong

competitive advantages in feed production line with the capacity of 1-30 tph and biomass pellet complete line

with capacity of 1-50tph.Until now,we had installed more than 1200 sets of machines worldwide.

In recent years,our company continuously increase investment.We had invested up to 60 million Yuan to build

19,200 square meters manufacturing base and 10 million Yuan for technological innovation,in-depth automatic

and integrative technology development.These investments have greatly promoted the upgrading of the machines,

offering best quality solutions for feed industry and biomass pellet industry.Double Crane Machinery is willing to

become your partner with our high price-performance products,excellent quality and perfect after-sales service.

About Professional Service:
1.We devote to all-round service of all the products from shipment to maintenance.
2.Our professional service include:free training,guidance,onsite installation,and debugging.
3.After selling, we provide the warranty of one year and free technical guidance and spares parts supply.
4.If your equipments have any problems, we will help you to solve online or onsite in time.
5.Welcome oversea agents to join us expand internation market.
6.Welcome to contact us for further information!

If you're interested in our feed pellet machines, please kindly reply us the following question:

1. What's the feed pellet production capacity do you want?

R:we can supply feed pellet mill or turn-key feed pellet production line output from 1-20t/h.
2. What's your feed raw material and size and feed formulaton content?

R:All kinds of feed material is workable to produce feed pellet,tell us we can design the suitable

   production line for you according to your actual demand.
3. What's the final feed pellet diameter do you want?

R:We can do feed pellet diameter 2-8mm or more,pellet length can be controlled by pellet mill's

   cutter device.
4. What's your country industrial electricity voltage?

R:Standard motor general need work under 380V,50Hz,3Phase,if not match,tell us we can modify motor.

1.What is your raw material to make the pellet?

2.What is the capacity of the pellet machine?

3. what animals will you feed?

4.what is the finished pellet size? Diamater and length

5. What is your country voltage? China is 380V 50HZ 3phase, is it same with yours?

                      Welcome your enquiry and we will reply you within 12 hours !!!
