MUST Factory Directly Low Frequency Split Phase hybrid Solar Inverter Charger 5KW
- Категория: >>>
- Поставщик: Must,Energy,(guangdong),Tech,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 536.80 $* | 563.31 $* |
| Aug-15-2025 | 531.68 $* | 558.75 $* |
| Jul-15-2025 | 446.4 $* | 468.52 $* |
| Jun-15-2025 | 522.85 $* | 548.11 $* |
| May-15-2025 | 455.63 $* | 478.61 $* |
| Apr-15-2025 | 513.45 $* | 539.61 $* |
| Mar-15-2025 | 509.66 $* | 534.48 $* |
| Feb-15-2025 | 504.19 $* | 529.39 $* |
| Jan-15-2025 | 500.74 $* | 525.70 $* |
Характеристики
Product Description
Spec
| Model | EP33-1012 TLV | EP33-1024 TLV | EP33-1512 TLV | EP33-1524 TLV | EP33-2012 TLV | EP33-2024 TLV | EP33-3024 TLV | EP33-3048 TLV | EP33-4024 TLV | EP33-4048 TLV | EP33-5048 TLV | EP33-6048 TLV |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inverter Output | ||||||||||||
| Rated power(W) | 1KW | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW | |||||
| Power Factor | 1 | |||||||||||
| Wave form | Pure sine wave/ Same as input waveform (bypass mode) | |||||||||||
| Output voltage RMS | 100V/110V/120VAC(200V/220V/240VAC)±10% | |||||||||||
| Output frequency | 50HZ or 60HZ (±0.3HZ) (can be set) | |||||||||||
| Overload protection | Breaker + software protection | |||||||||||
| Output short circuit | Breaker + software protection | |||||||||||
| Inverter efficiency(peak) | >80% | |||||||||||
| Overload | 100%<Load<110% (alarm 5min then stop output); 110%<Load<125% (alarm 60s then stop output); Load>125% (alarm 10s then stop output) | |||||||||||
| Surge rating | 3000VA | 4500VA | 6000VA | 9000VA | 12000VA | 15000VA | 18000VA | |||||
| Capable of starting electric motor | 1P | 1P | 1.5P | 1.5P | 2P | 3P | ||||||
| Battery | ||||||||||||
| Battery voltage | 12VDC/24VDC | 24VDC/48VDC | 48VDC | |||||||||
| Minimum start voltage | 11VDC/22VDC/44VDC | |||||||||||
| Low battery voltage cut off | (low voltage fault code04)10/10.5/11V for 12V model(*2 for 24DVC / *4 for 48VDC) | |||||||||||
| Low battery voltage alarm | Add 0.5V/battery: (low battery alarm one second one time) (10/10.5/11V) + 0.5Vdc for 12V model(*2 for 24DVC / *4 for 48VDC) | |||||||||||
| High battery voltage alarm | Add +1V/battery: (high voltage one second one time/after 30s fault 03) (13.8-14.5V) + 1V for 12V model(*2 for 24DVC / *4 for 48VDC) | |||||||||||
| Save mode | Load≤40W(110V)/80W(220V) | |||||||||||
| AC Input Mode | ||||||||||||
| Input waveform | Pure sine wave | |||||||||||
| Nominal input voltage | 220Vac / 230Vac / 240Vac | |||||||||||
| Max input voltage | 270Vac MAX | |||||||||||
| Input frequency | 50HZ/60HZ (auto sensing) | |||||||||||
| Efficiency(AC mode) | >95% (load, full battery) | |||||||||||
| Transfer time DC TO AC | 15ms(max) | |||||||||||
| Charge Mode | ||||||||||||
| Boost Voltage | 14.1V(Default) Range of adjustment 13.8-14.5V/*2 for 24VDC/*4 for 48VDC (Regulation step 0.1V) | |||||||||||
| Float Voltage | 13.5V(default) Range of adjustment 13.5-13.7V/*2 for 24VDC/*4 for 48VDC (Regulation step 0.1V) | |||||||||||
| 12V | 30A | 45A | 60A | |||||||||
| 24V | 20A | 25A | 30A | 40A | 60A | |||||||
| 48V | 20A | 30A | 35A | 40A | ||||||||
| Min charge current 10A. change by every 5A. | ||||||||||||
| Dimensions | ||||||||||||
| Dimensions (W*H*D) | 277*196*466mm | 277*186*621mm | ||||||||||
| Ship Dimensions (W*H*D) | 376*306*592mm | 376*296*747mm | ||||||||||
| Warranty | One year(standard),2years optional(IP20) | |||||||||||
Company Information
1. MUST Factory located in Huanan Chuanggu Science and Technology Park, Chancheng District, Foshan City. We are a high-tech manufacturer specializing in R&D, production, sales and service of industrial automation, new energy and power electronics related products.
2. MUST main products include: (UPS), Inverter, Photovoltaic Controller, Photovoltaic Inverter, Photovoltaic control inverter integrated machine, photovoltaic energy storage inverter, photovoltaic grid-connected inverter, Photovoltaic power generation system, photovoltaic pump system, microcomputer room system, dedicated loss converter, servo drive, servo motor, servo system
3. MUST's products have passed CE, SAA, SONCAP, SGS, Tell certification and other safety certifications, ISO: 9001, ISO: 14000 and other quality management system certification,
4. MUST products are exported to Spain, Italy, Russia, Australia, the Middle East, Ukraine, South Africa, Nigeria, Pakistan and other countries to provide customers with quality and efficient services.
Our Services
5kw 6kw 7kw 8kw Hybrid solar power Inverter for solar power system MPPT built inside
5kw 6kw 7kw 8kw Hybrid solar power Inverter for solar power system MPPT built inside
Packaging & Shipping
5kw 6kw 7kw 8kw Hybrid solar power Inverter for solar power system MPPT built inside
Certifications
5kw 6kw 7kw 8kw Hybrid solar power Inverter for solar power system MPPT built inside
FAQ
Q1: How to choose a right inverter?
A1:Tell us your demand, then our sales will recommend a suitable inverter to you.
Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.
Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.
Q4: What is the warranty of inverter?
A4: One year warranty on Must-Solar product.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
