BTCP-297A A4 копировальная бумага полосная упаковочная машина
US $19000-$43000
Автоматическая машина для упаковки шоколадных
- Категория: Wrapping Machines >>>
- Поставщик: Wenzhou,Echo,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 10115.8 $* | 10621.91 $* |
| Aug-15-2025 | 10030.2 $* | 10532.64 $* |
| Jul-15-2025 | 8415.47 $* | 8836.26 $* |
| Jun-15-2025 | 9860.28 $* | 10353.8 $* |
| May-15-2025 | 8585.78 $* | 9014.71 $* |
| Apr-15-2025 | 9690.28 $* | 10175.68 $* |
| Mar-15-2025 | 9605.69 $* | 10085.68 $* |
| Feb-15-2025 | 9520.4 $* | 9996.60 $* |
| Jan-15-2025 | 9435.49 $* | 9907.89 $* |
Характеристики
Product Description
Main Performance And Structure Features:
1. Automatic shows error in touch panel, safety shield, safety switch.
2. This system can store products’ parameters more than 100pcs. The touch screen shows everything in Chinese (English), operation indication, error signal and quantity.
3. Easy operation and size management via touch panel.
4. Pack size is independent of the product size: narrow and wider packs are possible.
5. Auto-splicer. Economic energy and packaging material usage.
6. Fast speed, less empty bags, steady packing capacity.
7. Easy to change the spare parts, whole structure designed for long time using.
8. Low noise. Use synchronization belt.
We also supply other devices:
1.Date coding printer, 2.Air-filling device, 3.Punching device
4.Double frequency converter controller / servo motor for choice
Note: We can design and make machine according to the customers’special needs.
| Machine parameters | ||
| Model | ECHO -800 | ECHO -1200 |
Capacity | Max 800 pcs/min(see different size) | Max 1100 pcs/min(see different size) |
Packing Spec. | Length 12-40mm Width 12-30mm Height 5-18mm | Length 12-40mm Width 12-30mm Height 5-18mm |
Length of Finished bag | 50-80mm | 50-80mm |
| Power | 220V 50/60HZ 4KW | 220v 50/60hz 4kw |
Machine Size(mm) (L*W*H) |
2450x1150x1550mm
| 2800*1350*1720mm |
| Machine Weight | 950kg | 1400kg |
| Thickness of the film |
0.030-0.05mm | |
| Candy Shape | Square, Ellipse, Oblate, Globular, Plum Blossom-Shaped | |
Application Product | It wraps products such as rectangular, square, flat or round pieces of chewy candy toffees, milk toffees, chewing gum and so on in tight single or multi-piece packs. | |
| Packing Material | OPP,CPP,PET Metallized film, Al-plastic film, Paper-rubber complex,etc. | |
Working Hour (suggestion): | less than 24 hours per day. | |
| Parts of Machine | ||||||||
| Parts | Touch Screen | PLC | Servo Motor | Cylinder | proximity switch | Photo Sensor | Solid State Relay | Temperature Controllor |
| Brand | SIEMENS | SIEMENS | PANASONIC | AIRTAC | TOSHIBA | SICK | SHENGLONG | OMRON |
| Oringin | Germany | Germany | Japan | China | Japan | Germany | China | Japan |
| The Parts Can Be Replaced As Your Need. | ||||||||
Our Services
Pre-sale Service
1. Equipment model selection;
2.according to the special requirements of customers, personalized customized products;
3. Train technicians for customers free of charge;
4. Free professional technical engineers to plan the site on site and design the best process and plan.
2.according to the special requirements of customers, personalized customized products;
3. Train technicians for customers free of charge;
4. Free professional technical engineers to plan the site on site and design the best process and plan.
5. Acceptance of the product;
6. Assist the client in drafting the construction plan;
6. Assist the client in drafting the construction plan;
Medium-sales Services:
ECHO have the trained team to follow your orders methodically to guarantee the products can be finished on time with high quality.
ECHO have the trained team to follow your orders methodically to guarantee the products can be finished on time with high quality.
After-sales Service
1.One Year Warranty
As long as there is a non-human fault in a year,free re-placement parts.
2.Parts Replacement
Don’t worry about the parts damaged or not sold after the machine is sold.we have a field factory with hundreds of enployees to serve you.
3.Engineer Asssignment
Lifelong maintentance,If your equipment breaks down,we will arrange engineers to repair it.
4.Online Instruction
We open online services,as long as your equipment failure,our engineers will be the first time for a one-to-one trou-bleshooting.
5.Feedback Survey
The engineer is required to bring a questionnaire to fill in the satisfaction with the engineer and the use of the equipment.
As long as there is a non-human fault in a year,free re-placement parts.
2.Parts Replacement
Don’t worry about the parts damaged or not sold after the machine is sold.we have a field factory with hundreds of enployees to serve you.
3.Engineer Asssignment
Lifelong maintentance,If your equipment breaks down,we will arrange engineers to repair it.
4.Online Instruction
We open online services,as long as your equipment failure,our engineers will be the first time for a one-to-one trou-bleshooting.
5.Feedback Survey
The engineer is required to bring a questionnaire to fill in the satisfaction with the engineer and the use of the equipment.
Company Information
Echo Machinery CO.,LTD is manufacturing and trading company which is mainly engaged in the R&D, manufacture,marketing and service of plastic & paper bag food packaging machinery with more than 20 years in China.
The aim of Echo is to give you a hand and assist you to solve your package problems with most suitable solution.
We are specialized in packing machine
1.Rotary packing machine
2.Horizontal bag making&packing machine
3.High speed vertical packing machine
4.Pillow packing machine
5.Vacuum packaging machine
We provide professional packing solution and do a series of service from beginning to end
Our strength
1.Equipment make and assemble strictly in accordance with CE,ISO9001(certification) standard in our own CNC.
2.20years experience in packing industrial with good after-sale service group
3.Our professional team of research and development has got our own paten for invention
4.Professional sales and engineer team with 24 hours hot line to do design packing project, problem consulting,soultion.
5.Professional engineers group as after-service team can speak English and do overseas service.
We continually design new model and improve machines and solutions to satify different and stringent requirements from market.
Our professional pre-sales and after-sales service guarantee the complete satifaction of the equipments.Welcome to work with us to win a mutual benfit future.
Packaging & Shipping
Contact US
Company Address:
No. 81, Dongsan Road, Nanbin Street, Ruian City, Zhejiang Province,China
If You Would Like To Visit Our Just Now,Plese Contact Us and We Will Arrange a Special Bus To Pick You Up.
Kindly Reminder:
Please let us know the follow packing details when you offer,so that we can check if this model is suitable for your case.Thank you in advance.
1. Product details
2. Bag width,bag length
3. Bag shape
4. Packing film material
5. Machine frame
ECHO MACHINERY is still developing, and the products are also being innovated.
Welcome our old and new customers to visit our factory and make the consultation.
We will provide professional packaging solutions for you!
