 Cooperation mode:

1. Schematicdesign: circuit schematic can be designed according to customer’s requirements.



2, PCB design: PCB diagram can be designed according to the schematic from customer. PCB and bill of materials can be analyzed on the basis of customer’s samples.



3, Software design: SCM software development and design, can be written according to customer’s requirements, with the needed function. Or rewrite some part of software to fit customer's actual hardware.



PCB PROCESSING CAPABILITY :

1	Layers	Single Sided,2 to 18 Layer
2	Board material type	FR4,CEM-1,CEM-3,ceramic substrate board, aluminum based board, high-Tg, Rogers and more
3	Compound material lamination	4 to 6 layers
4	Maximum dimension	610 x 1,100mm
5	Dimension tolerance	±0.13mm
6	Board thickness coverage	0.2 to 6.00mm
7	Board thickness tolerance	±10%
8	DK thickness	0.076 to 6.00mm
9	Minimum line width	0.10mm
10	Minimum line space	0.10mm
11	Outer layer copper thickness	8.75 to 175µm
12	Inner layer copper thickness	17.5 to 175µm
13	Drilling hole diameter (mechanical drill)	0.25 to 6.00mm
14	Finished hole diameter (mechanical drill)	0.20 to 6.00mm
15	Hole diameter tolerance (mechanical drill)	0.05mm
16	Hole position tolerance (mechanical drill)	0.075mm
17	Laser drill hole size	0.10mm
18	Board thickness and hole diameter ratio	10:1
19	Solder mask type	Green, Yellow, Black, Purple, Blue, White and Red
20	Minimum solder mask	Ø0.10mm
21	Minimum size of solder mask separation ring	0.05mm
22	Solder mask oil plug hole diameter	0.25 to 0.60mm
23	Impedance control tolerance	±10%
24	Surface finish	Hot air level, ENIG, immersion silver, gold plating, immersion tin and gold finger













 Mode of production cooperation:

1. The written program, schematic, PCB data and bill of materials can be sent to customer for the processing of program  and circuit boards.



2, We can design the program for customer, help to produce circuit boards according to customer’s requirements. Multi-style cooperation to meet different customer’s needs.



3, Development and design, low charge. only cost and development fees are required, which can be returned after a certain amount of orders. Can be developed and designed on basis of customer's program requirements.





Designable PCB board:

Intelligent circuit boards for domestic appliance, like electric water heaters, rapid thermal water heaters, solar water heaters, air conditioners, refrigerators, microwave ovens, dishwashers, disinfection cabinets, water dispensers, washing machines, vacuum cleaners, rice cookers, cold fans, water purifiers, etc.
