Лазерный сварочный аппарат 200A AC / DC WIG Mig Tig инвертор для сварки алюминия MMA + оборудование плазменной

• The New Welder WIG-200P allows you not only weld steel, but also weld low-and high-alloy steels, nickel-based alloys, copper, and special materials and other ferrous metals with DC function (direct current). For precision welding of cast aluminum components and non-ferrous metals (brass, bronze), AC/DC TIG 200 PULSE features with an AC function.


• Compared to conventional welding equipment, the unique HF Inverter technology has many advantages. Smaller volume, reduced weight, continuously variable regulation, energy saving etc.. The application of inverter technology allows a focused and permanent power output. This made much more precise and practical. The AC/DC WIG-200P Welder includes the most modern, innovative, easy-to-use quality engineering,


• so even beginners with the TIG welding process work easily.

Superiority:

1. 4 In 1 combination welding device - TIG Inverter with AC- and PULSE-Function, and manual metal arc stick welding (MMA).
2. Antistick - Prevents annealing of the electrode (less consumable electrodes), because the power is immediately terminated.
3. Hot Start - Automatic voltage increase at the start.
4. HF Ignition - High-frequency contactless ignition to the workpiece.
5. MMA - Manual metal arc welding.
6. CUT contact - Absolutely easy-to-use HF high-frequency contact ignition. A light stroke over the workpiece is sufficient.
7. Plasma Cutter - With the integrated Plasma Cutter 50 A  can be cut without problems all conductive metals. For example: aluminum, steel, copper, brass, titanium and so on (depending on material).
8. Gas magnet valve - Opens only when the hand torch is operating and closes when the welding process is finished.
9. Over heat protection - When temperature of machine exceed the required standard, the welding machine will stop working automatically. A red indicator light turns on and turns off when the device is cooled down again.
10. Automatic cooling ventilators - Quickly cooling ventilator allows a exploitation of maximum power.
11. Highest efficiency for all requirements with reproducible welding results and excellent quality through the fully digital inverter welding technology.
12. Easy to understand operating concepts for each choice of particular setting, so you can concentrate fully on your welding task.
13. Through powerful TIG arc - Faster, better and easier welding across the entire power range.

Application

The welding equipment is particularly suitable when quality welds are extremely important. Private gardening: motorcycles, cars, trucks, classic cars, model making, stair and balcony railings; or in the professional and industrial sectors such as shipbuilding, metal, metalwork, aircraft, garden, landscaping and welding schools, the highest quality requirements are met successfully with our welding equipment.

Notice

1. Avoid welding in sunshine or drippings.
2. The working area is adequately ventilated!
3. Do not over load! No over voltage!
4. The welding machine has installed protection circuit of over voltage and current and heat. When voltage and output current and temperature of machine are exceeding the rate standard, welding machine will stop working automatical

Details:

• op quality but affordable


• Compact, safe, practical and efficient


• Powerful and comfortable


• Always a clean weld on all workpieces


• Precision metering with TIG pulse function


• Intelligent housing design with optimized air exchange


• A professional device for daily use


• Two years warranty

• 1 X WIG-200P Welding Machine


• 1 X 4.5M Cutting Torch


• 1 X 5M TIG Torch


• 1 X 3M Wire With Ground Clamp


• 1 X 3M Cable With Electrode Holder


• 1 X 3M Hose


• 1 X Reducing Valve


• 1 X Product Manual
