Чешская Республика 11 кВт Wifi функция воздушно-водяной тепловой насос

Описание и отзывы

Трекер стоимости

Характеристики

Air source heat pump/Air to water heat pump(heating+hot water 60degree)
Model			unit	FA-03
Rated heating capacity			KW	11
			BTU	37543
Hot water supply			T/h	0.23
Average heating input power			KW	2.34
Rated heating input current			A	11.2(220V)
				6.5(380V)
Max outlet water temp			℃	60℃
COP				4.62
Power			V/Hz	220-240V/380-415V/50HZ
Nosie			dB(A)	50
Dimension		Width	mm	1100
		Deepth	mm	460
		Height	mm	687
Unit weight			KG	120
Throttling type				Electronic expansion valves
Refrigerant				R410A
Working air temp range				– 20℃~45℃
Compressor	Type			Scroll Copeland,.hitachi,panasonic
	Security functions			Built-in protection device overheating protection, sequence protection, undervoltage protection, delay protect
Air source heat exchanger	Type			Finned heat exchange
	Qty		piece	1
	Fan type			Axial big twist Angle fan
	Motor power		W	50
Hot water side heat exchange	Type			tube in shell heat exchanger/plate heat exchanger
	Water flow		m3/H	1.86
	Water pressure down		kPa	27
	Pipe size		Inch	0.75
	Water side max working pressure		kPa	1000

Remarks:the test conditions of above parameter:dry bulb temp is 20℃.wet buld temp is 17℃.inlet water temp is 15℃.outlet water temp is 60℃
