281kw геотермальный тепловой насос водяной (нагрев + горячая

281kw геотермальный тепловой насос водяной (нагрев + горячая

Категория: Нагреватели воды с тепловым насосом >>>
Поставщик: Guangdong,Folansi,Energy,Saving,Equipment,Co.,Ltd.

Цена:14 000,00 $ - 15 000,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	16660.98 $*	17493.48 $*
Aug-15-2025	16520.20 $*	17346.80 $*
Jul-15-2025	13860.93 $*	14553.69 $*
Jun-15-2025	16240.84 $*	17052.95 $*
May-15-2025	14140.57 $*	14847.42 $*
Apr-15-2025	15960.55 $*	16758.14 $*
Mar-15-2025	15820.73 $*	16611.68 $*
Feb-15-2025	15680.35 $*	16464.7 $*
Jan-15-2025	15540.87 $*	16317.67 $*

Характеристики

Name:Geothermal heat pump/Water to water heat pump(Heating and hot water)
Model		Unit	FW-75	FW-90
Rated heating capacity		kw	280.9	346
Rated heating capacity		BTU	958431	1180552
Hot water supply		T/h	6.04	7.44
Rated input power		kw	56.06	67.64
Rated heaing input current		A	97.4	117.5
COP			5.01	5.12
Max running current		A	170.6	180.9
Power		V/Ph/Hz	380-415V/50Hz
Noise		dB(A)	74	76
Dimension	Width	mm	2700	2700
	Deepth	mm	850	850
	Height	mm	1550	1550
Weight		kg	1380	1650
Throttle typ			Electronic expansion valves/thermal expansion valves
Refrigerate			R417A, R407C,R22
Max outlet water temp			60℃
Compressor	Type		Copeland,Danfoss
	Qty		3	3
	Locked-rotor current	A	272	310
	Security protect functions		Built-in protection device overheating protection, sequence protection, undervoltage protection, delay protect
Water source side heat exchange	Type		Efficient shell tube heat exchanger
	Water flow	m³/h	38.66	47.87
	Water pressure down	kPa	30 ~ 70
	Pipe size	Inch	4	5
Hot water side heat exchange	Type		Efficient shell tube heat exchanger
	Water flow	m³/h	48.3	59.5
	Water pressure down	kPa	30 - 70
	Pipe size	DN	4	5

Rated heating working condition: heat source side heat exchnage inlet water temp 15℃, hot water side heat exchnage beginnig of temp 15℃,end of temp 60℃
Rated heating working condition: heat source side heat exchnage inlet water temp 15℃, hot water side heat exchnage beginnig of temp 15℃,end of temp 60℃
