Shotcrete Machine
Китайский поставщик высокое качество машина для мокрого дробовика на

Китайский поставщик высокое качество машина для мокрого дробовика на

Категория: Shotcrete Machine >>>
Поставщик: Qingdao,Co-Nele,Group,Co,.ltd.

Цена:14 000,00 $ - 15 500,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	16660.57 $*	17493.46 $*
Aug-16-2025	16520.54 $*	17346.32 $*
Jul-16-2025	13860.13 $*	14553.74 $*
Jun-16-2025	16240.58 $*	17052.41 $*
May-16-2025	14140.1 $*	14847.35 $*
Apr-16-2025	15960.56 $*	16758.72 $*
Mar-16-2025	15820.86 $*	16611.9 $*
Feb-16-2025	15680.4 $*	16464.13 $*
Jan-16-2025	15540.95 $*	16317.50 $*

Характеристики

Product Description

Wet shotcrete machine for sale

SPJ08-07-22 concrete wet spraying machine have 1-8m3/h spraying capacity and are powered by 380V/50Hz, electric motors. Concrete wet spraying machine have rugged construction for long usage life and a compact design for easy operation. It is widely used in mine roadway, railway and highway tunnels, water conservancy culverts, underground engineering and other construction.

Technical parameter

	The parameter name	Unit	Parameter
Performance	The maximum theoretical spray output	m³/h	0-8
	The maximum theoretical pumping pressure	Mpa	7
	The maximum pumping frequency	Time/min	16
	Distributing valve form		S valve
	Delivery cylinder specification	mm	Φ140*800
	Discharging outlet diameter	mm	125
	Delivery hose	mm	Φ80
	The dia.of spray gun	mm	Φ50
	Feeding height	mm	700
Power system	The rated voltage	V	380
	Main motor power	KW	22
	Rated speed	r/min	1470
Hydraulic system	Hydraulic circuit form		Open circuit
	The main system MTP	Mpa	25
	The hydraulic oil tank volume	L	120
Other parameters	The maximum aggregate size	mm	15
	Delivery pipe diameter	mm	Φ57
	Whole machine weight	kg	2000
	Towing speed	Km/h	≤8
	Overall dimensions(lengthwidthheight)	mm	340015001550
