Инвертор солнечной энергии 10 кВт 20 25 30 40 50 ква

Инвертор солнечной энергии 10 кВт 20 25 30 40 50 ква

Категория: Солнечные инверторы >>>
Поставщик: Shenzhen,Topsky,Energy,Co.,Ltd.

Цена:51 983,16 ₽ - 218 479,91 ₽*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-15-2025	66018.79 $*	67338.51 $*
Jul-15-2025	53542.55 $*	54613.1 $*
Jun-15-2025	64979.19 $*	66279.48 $*
May-15-2025	64459.40 $*	65748.48 $*
Apr-15-2025	51463.26 $*	52492.65 $*
Mar-15-2025	63419.17 $*	64687.29 $*
Feb-15-2025	62899.33 $*	64157.68 $*
Jan-15-2025	62380.92 $*	63628.76 $*

Характеристики

Product Description

10kw 20kw 25kw 30kw 40kw 50kw 10kva 20kva 30kva 40kva 50kva Growatt Grid Tied Solar Power Inverter

Growatt inverter 15kw

Datasheet	12000-S	13000-S	1500-S
Input Data
Max. recommended PV power (for module STC)	14400	15600W	18000W
Max. DC voltage	1000V	1000V	1000V
Start voltage	160V	160V	160V
MPP work voltage range	200V -1000V	200V -1000V	200V -1000V
Nominal voltage	600V	600V	600V
Max. input current	20A/10A	20A/10A	20A/10A
Number of independent MPP trackers/strings per MPP tracker	2/2+1	2/2+1	2/2+1
Output (AC)
Rated AC output power	12KW	13KW	15KW
Max. AC power	13.2KVA	14.3KVA	16.5KVA
Max. output current	19A	20.6A	23.8A
AC nominal voltage	230V/400V;320-478V	230V/400V;320-478V	230V/400V;320-478V
AC grid frequency; range	50Hz/60Hz	50Hz/60Hz	50Hz/60Hz
Adjustable power factor	0.8leading...0.8lagging	0.8leading...0.8lagging	0.8leading...0.8lagging
THDI	<3%	<3%	<3%
AC connection	3W+N+PE	3W+N+PE	3W+N+PE
Efficiency
Max. efficiency	98.4%	98.4%	98.4%
Euro weighted efficiency	97.8%	98%	98%
MPPT efficiency	99.5%	99.5%	99.5%
Protection Devices
DC reverse polarity protection	yes	yes	yes
DC switch	yes	yes	yes
Output over current protection	yes	yes	yes
Output AC overvoltage Protection - Varistor	yes	yes	yes
Ground fault monitoring	yes	yes	yes
Grid monitoring	yes	yes	yes
Integrated all-pole sensitive leakage current monitoring unit	yes	yes	yes
General Data
Dimensions (W / H / D) in mm	480/448/200	480/448/200	480/448/200
Weight	23.5kg	23.5kg	23.5kg
Operating temperature range	–25°C ... +60°C	–25°C ... +60°C	–25°C ... +60°C
Noise emission (typical)	≤25 dB(A)	≤25 dB(A)	≤25 dB(A)
Self-Consumption night	<0.5 W	<0.5 W	<0.5 W
Topology	Transformerless	Transformerless	Transformerless
Altitude	Natural	Natural	Natural
Environmental Protection Rating	IP65	IP65	IP65
Relative humidity	3000m	3000m	3000m
Cooling concept	100%	100%	100%
Features
DC connection	H4/MC4(opt)	H4/MC4(opt)	H4/MC4(opt)
AC connection	Connector	Connector	Connector
Display	LCD	LCD	LCD
Interfaces: RS232/RF/Wi-Fi/ LAN/GPRS	yes/opt/opt/opt/opt	yes/opt/opt/opt/opt	yes/opt/opt/opt/opt
Warranty:5 years/10 years	yes/opt	yes/opt	yes/opt
CE, VDE 0126-1-1, IEC 62109, G83, AS4777, AS/NZS 3100, CEI0-21, VDE-AR-N4105, EN50438, CQC, UTE C 15-712, IEC 61683, IEC 60068, IEC 61727, IEC 62116, INMETRO
