Характеристики
Product Description
The main performance characteristics:
Reinforced type gear, transmission torque large
B1 type optional2-speed motor, spindle speed range widely.
Application:
Widely used in single or batch is machinery manufacturing industry; instrument; building decoration and repair department.
Product main technical Specifications:
Reinforced type gear, transmission torque large
B1 type optional2-speed motor, spindle speed range widely.
Application:
Widely used in single or batch is machinery manufacturing industry; instrument; building decoration and repair department.
Product main technical Specifications:
Specifications | ZX7016 |
Max. Drilling capacity (mm) | 16 |
Max. face mill capacity (mm) | 40 |
Diameter of vertical milling (mm) | 10 |
Spindle travel (mm) | 80 |
Distance spindle axis to column generating line (mm) | 182 |
Max. Distance spindle nose to table (mm) | 360 |
Spindle taper | MT2 |
Spindle speeds range (r/min) | 320~3300 |
Spindle speeds series | 12 |
Dimension of worktable surface (mm) | 420×152 |
Table travel (mm) | 230×120 |
Overall height (mm) | 900 |
Main motor (W) | 550 |
G.W/N.W(Kg) | 100/75 |
Packing dimension (cm) | 65×58×77 |
Details Display
