150m deep tractor mounted diesel water well rock drilling machine water well drilling rig
Portable small water well drilling rig for sale
Small trailer borehole water well drilling rig for sale
Movable Portable Hydraulic Used for Borehole Water Well Drilling Rig Machine
Portable Small Diesel Engines Water Well Drilling Rig
Multifunction Hydraulic Drilling Rig For Water Wells
600m depth water well drilling rig/water swivel for drilling rig/drilling equipment for water manufacture factory Depth Borehole 300m Water Well Drilling Rig Machine For Sale
Full hydraulic pprtable minin water well drilling rig machine for sale
Portable small water well drilling rig for sale
Small trailer borehole water well drilling rig for sale
Movable Portable Hydraulic Used for Borehole Water Well Drilling Rig Machine
Portable Small Diesel Engines Water Well Drilling Rig
This machine mainly used for geothermal drilling, farm irrigation , house yard, gardens and water well drilling, drilling diameter is 70-350mm, and drilling depth is 80m to 100m. It also can be used in small building piling, like farmhouse or factory, the drilling diameter can reach 600mm and depth can be more than 120 meter.
The advantage of the water well drilling machine are as below:
1. Light weight, energy saving.
2. Patented product, unique design and simple drilling structure;
3. Easy to transport and can learn how to handle the machine in short time;
4. Can drill through hard stratum, unless thick rock layer ;
5. One person operation, reduce the labor intensity ;
6. High efficiency and work fast.
7. Assure easily operation and long life service life
Small trailer borehole water well drilling rig for sale
Portable Small Diesel Engines Water Well Drilling Rig
Technical Parameters of ZX-500 Tractor mounted water well drilling machine | |
Model of drilling machine | ZX-500 |
Drilling machine overall dimension(mm) | Base:90*150cm,height:2m |
Weight of Drilling machine (kg) | 600 |
Drill rod diameter (mm) | Ø65 |
Drill rod length(mm) | 2000 |
Rod change method | Full automatic screw thread |
Drilling depth(m) | 150 |
Voltage (V) | 380V |
Motor power (KW) | 11KW |
Drilling method | Percussive and rotating type |
Pump power (KW) | 7.5KW |
Drilling hole diameter(mm) | Within Ø 500mm |
Hosting height(mm) | 2000 |
Hosting capacity (kg) | 1000 |
Type | Electric type machine |
Model of drilling machine | HY-500 wheel type |
Drilling diameter | 200-450mm |
Drilling depth(m) | 100-150m |
Drill rod diameter (mm) | Ø63.5 |
Drilling speed | 60rpm/90rpm Double speed |
Water pump | 7.5kw ,with pipe,cable and others |
Speed of the drilling rod | 1.5m |
Drilling rod change type | automatic |
Drilling rod |
|
PDC drilling rod |
|
Electric box | 1 |
Hydraulic pump motor | 3kw motor |
Gear pump | CB-32 ,1 Unit |
Gear pump base | 1 |
Drill pipe handling device | 1 |
Rod change method | Full automatic screw thread |
