Покрытие поверхности Лазерная очистка 1000 Вт лазерная металла пресс-форма
- Категория: Fiber Laser Cleaning Machine >>>
- Поставщик: Jinan,Lxshow,Laser,Manufacture,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 11781.1 $* | 12370.8 $* |
| Aug-15-2025 | 11682.2 $* | 12266.22 $* |
| Jul-15-2025 | 9801.68 $* | 10291.15 $* |
| Jun-15-2025 | 11484.61 $* | 12058.80 $* |
| May-15-2025 | 9999.60 $* | 10499.52 $* |
| Apr-15-2025 | 11286.71 $* | 11850.32 $* |
| Mar-15-2025 | 11187.38 $* | 11746.88 $* |
| Feb-15-2025 | 11088.9 $* | 11642.42 $* |
| Jan-15-2025 | 10989.31 $* | 11538.49 $* |
Характеристики
Machine Application
LASER CLEANING MACHINE
- This is what we can do
A. Metal surface cleaning
B. Removal paint of metal surface
C. stains cleaning on the surface
D. Surface coating cleaning
E. Pretreatment of welding surface cleaning
F. Stone surface cleaning
G. Rubber mold residue cleaning
B. Removal paint of metal surface
C. stains cleaning on the surface
D. Surface coating cleaning
E. Pretreatment of welding surface cleaning
F. Stone surface cleaning
G. Rubber mold residue cleaning
H. Non-metal material, such as wood.
Ship Industry, auto Parts, rubber Mold, high-end Machine, tire molde track, environmental Protection Industry and others.
Ship Industry, auto Parts, rubber Mold, high-end Machine, tire molde track, environmental Protection Industry and others.
"Clean‘’ a New Clothes for A Better Tomorrow
Product Description
We have our OWN FACTORY, so we can provide you with a full range of services.
* FREE Visiting (Support Real-time video)
* FREE Training
* FREE Training
* FREE Testing
* FREE Samples
When the laser cleaning machine finished production, we will test and package the machine well, To ensure that our customers can use the machine soon after receiving it, saving customers time is to create more value for customers
What You Want
1. What's the machine package size?
L*W*H: 1240*710*1040mm; Cross Weight:140kg
2. How to confirm the machine cleaning effect?
Please tell us your needs, we will finish the testing video for you, and we also support real-time video, You can observe the cleaning effect of the machine more directly.
3. Is there any damage to the cleaning material?
Depends on what type you need, the pulse type has a finer cleaning effect, and the continuous type has a faster cleaning speed, Relative damage of material, pulse type is less than continuous type.
Depends on what type you need, the pulse type has a finer cleaning effect, and the continuous type has a faster cleaning speed, Relative damage of material, pulse type is less than continuous type.
4. What are consumable parts?
Protective glass, etc, if you order, we will send it to you together with machine.
Protective glass, etc, if you order, we will send it to you together with machine.
5. When I get the machine, how to operate the machine?
We have machine manual, and we have professional after sale group, if you have any questions, they can help you anytime.
We have machine manual, and we have professional after sale group, if you have any questions, they can help you anytime.
6. Do the machine can be customized according to my own requirements ?
Sure, we have a strong technical team and have rich experience. Our final service goal is to let you satisfied.
Sure, we have a strong technical team and have rich experience. Our final service goal is to let you satisfied.
Machine Features
Raycus Laser Generator 100w
100w laser generator with air cooling, we have different laser generator brand and different laser power can be chosen.
Raycus Cleaning Head
Through the connection with the laser, through the completely sealed optical channel in the cavity, an energy spot is formed
Controller System
Raycus system, support english language, machine working buttons are fully equipped, which makes the operation more convenient and safer.
Controller Box
Each component, each line, reasonable placement, convenient maintenance of the machine, prolong the life of the machine.
* From Video, Know More about the Laser Cleaning Machine
Specification
Item | Specifications |
Power | Raycus 100W |
Laser head | Raycus RFL-7C-0100 |
Weight of the laser head | 2KG |
Scanning width | 10-100mm |
Average laser power | ≥100W |
Output power instability | ＜5% |
Power adjustment range（%） | 10-100(Gradient adjustable) |
Pulse width（ns） | 130-160 |
Central wavelength（nm） | 1064±5 |
Repeat frequency（kHz） | 10-50 (Gradient adjustable |
Maximum single pulse energy（mJ） | 1 |
Peak power（kW） | 90 |
Core（μm） | 30 |
Standard cable length | 5M |
Cleaning thickness（mm） | 1 |
Cleaning efficiency（m2/h） | 10 |
Focal length（mm） | 160/210 Replaceable |
Cooling method | Air cooling |
Consumption | 1000W |
Laser Source Optional | IPG MAX JPT |
Laser Power Optional | 50w 200w 300w 500w 1000w 1500w 2000w |
Optional Parts and Style
Different Customer as Different Needs; More Optional , More chosen.
^ ^ Here, you will surely find the one that suits you!
Tell us your needs, we will recommend the suitable soluation to you.
(The section is limited, just list some)
Raycus laser generator
Different laser power can be chosen, 200w 300w 500w 100w 1500w 2000w,etc, we also have different laser brand.
Water Chiller
Water cooling way. the machine has two cooling ways, one is air cooling, another is water cooling. depends on power.
Laser cleaning head
Differnet cleaning head can can optional, just tell us your needs, we will give you a suitable soluation.
Your Choice, Our Responsibility
* Jinan Lxshow Laser Manufacture Co., Ltd.
is established in July 2004, owns more than 500 square meters of researching and officespace, more than 32000 square meters factory. All machines , passed the European Union CE authentication.
* Certification Display
About machine quality, we have get the third party certification, and about the machine, we have 2 years machine warranty, if you need, we always here.
Our machines have participated in many exhibitions, and received enthusiastic attention from everyone at the exhibition
* Customer Feedback
If you have a plan to visit our factory, please tell us your schedule, we will book a hotel for you and arrange a driver. we also support real-time video.
* After Sale Group
Every machine, we will equipment with the machine manual, and we also have after sale group, if you need, just tell us anytime, when we get you help, we will reply you in the first time.
Create More Value for You
In our factory, we also have other machine style, if you have any other work that want to finish, hope the following solution can help you.
* Fiber laser Cutting machine
* Fiber laser welding machine
The whole Process: Metal Cutting ---> Metal Welding ---> Metal Cleaning
Suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, If you equipped with the rotary axis, Metal Plate, Tubes and Pipes, all ok.
Suitable for welding gold, silver, titanium, nickel, tin, copper, aluminum and other metals and their alloy materials. It can achieve the same precision welding between metals and dissimilar metals. It has been widely used in aerospace, shipbuilding, and instrumentation., Mechanical and electrical products, automobiles and other industries.
