Автоматический гибочный станок для резки


Поделиться:


Цена:11 000,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-20-2025 13090.49 $* 13745.52 $*
Aug-20-2025 12980.38 $* 13629.46 $*
Jul-20-2025 10890.97 $* 11435.53 $*
Jun-20-2025 12760.13 $* 13398.80 $*
May-20-2025 11110.63 $* 11666.1 $*
Apr-20-2025 12540.39 $* 13167.17 $*
Mar-20-2025 12430.67 $* 13052.83 $*
Feb-20-2025 12320.51 $* 12936.56 $*
Jan-20-2025 12210.45 $* 12821.40 $*

Характеристики



Product Description












































































Model



Bawang 2



Production efficiency *(pcs/hour)



1800



Single-line processing capacity





Class I round steel


:
4-12



Pneumatic expansion (can be customized if needed)



Yes



Grade III threaded steel4-12



Pneumatic expansion (can be customized if needed)



Yes



Double-line processing capability



Class I round steel


:
4-10



Maximum bending angle (positive, reverse)



 180° positive and negative



Grade III threaded steel:4-8



Maximum feed rate (mm/s)



1500



Bending center wheelbase height (mm)



1180



Maximum bending speed(°/s)



800



Total installed capacity(kw)



22



Length accuracy(mm)



±1



Mainframe dimensions(mm)



3280x1000x1700



Angle accuracy(°)



±1



Main  engine weight(kg)



1550kg



































Characteristics


1. Fully automatic steel bar bending machine production equipment, with straightening function, multi-purpose machine.


 2, using intelligent control, can process a variety of sizes of a variety of square, shape, diamond, polygon and so on.


3, from the wire rod raw material to the stirrup product once formed, can process cold, hot rolled high-strength wire rod steel.


 4, high production efficiency, equivalent to 20 to 30 labor.


 5, the steel bending machine is practical, only one person to operate, saving a lot of labor.


  6, saving raw materials, in the work is continuous molding almost no loss of steel head.


 7. Small footprint, saving straightening work area and cutting work area, can work in narrow areas.


 8. Reinforced bending hoop machine protection cost and energy consumption cost is very low. Comparison between automatic bending forming machine and traditional manual semi-mechanical production: traditional manual semi-mechanical (straightening---shear-bending-----forming)


















Packaging & Shipping


 Wooden cases & 30 days after payment


.jpg





Company Information







FAQ


 Q:Where are we located in?

   A:We are in Xingwan Industrial Zone Xingtai city Hebei province,China.

2.Q:How is your factory?

   A: We are factory specializing in the manufacture and export of machines for more than 20 years, all of the production we sale are at a very best price and high quality.

3.Q: What is your terms of packing?

A: Generally, we pack our goods in plywood cases.

4.Q:What is your terms of payment?

A: T/T 30% as deposit, balance before shippment

5.Q: Warrantee and After-sale service ?

A: 12 months warrantly, man-made destory will be exception.

B: After the warrantee time, we can supply materials or teach support to you for reducing the cost of you.

6.Q:Delivery time ?

A: 15-20 days for OEM, 5-7days for ready goods.

7.Q. Can you produce according to the samples?

A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

8. Q. How do you make our business long-term and good relationship?

A:1. We keep good quality and competitive price to ensure our customers benefit ;

2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.

9. Q. How to contact us?


Jessie zhao
