Неэлектрифицированный Гибридный солнечный инвертор с контроллером заряда mppt 3 кВт
- Категория: Продукты солнечной энергетики >>>
- Поставщик: Shenzhen,Jinsdon,Lighting,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.24 $* | 0.72 $* |
| Aug-17-2025 | 0.69 $* | 0.64 $* |
| Jul-17-2025 | 0.84 $* | 0.62 $* |
| Jun-17-2025 | 0.72 $* | 0.68 $* |
| May-17-2025 | 0.79 $* | 0.77 $* |
| Apr-17-2025 | 0.17 $* | 0.42 $* |
| Mar-17-2025 | 0.33 $* | 0.24 $* |
| Feb-17-2025 | 0.29 $* | 0.27 $* |
| Jan-17-2025 | 0.63 $* | 0.53 $* |
Характеристики
Product Description
1.5kw 3kw 5kw solar system mppt solar charge controller with solar inverter
This is a multi-functional inverter/charge, combining functions of inverter, solar charge and battery charge to offer
uninterruptible power support in portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
This is a multi-functional inverter/charge, combining functions of inverter, solar charge and battery charge to offer
uninterruptible power support in portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
Specification
MODEL | Glory M1500 HHS-24 | Glory M3000 HHS-24 | Glory M5000 HHS-48 | Glory M5000 HHP-48 | ||||
Capacity | 1.5KVA/1.5KW | 3KVA/3KW | 5KVA/5KW | 5KVA/5KW | ||||
Parallel Capability | NO | NO | NO | YES, 9units | ||||
INPUT | ||||||||
Nominal Voltage | 230VAC | |||||||
Acceptable Voltage Range | 170-280 VAC (For Personal Computers),90-280 VAC (For Home Appliances) | |||||||
Frequency | 50/60HZ (Auto sensing) | |||||||
OUTPUT | ||||||||
Nominal Voltage | 220/230VAC ± 5% | |||||||
Surge Power | 3000VA | 6000VA | 10000VA | 10000VA | ||||
Frequency | 50Hz/60Hz | |||||||
Waveform | Pure Sine Wave | |||||||
Transfer Time | 10ms (For Personal Computers) ; 20ms (For Home Appliances) | |||||||
Peak Efficiency (PV to INV) | 97% | |||||||
Peak Efficiency (Battery to INV) | 93% | |||||||
Overload Protection | 5s@>=150% load; 10s 110%~150% load | |||||||
Crest Factor | 3:1 | |||||||
Admissible Power Factor | 0.6~1(inductive or capacitive) | |||||||
BATTERY | ||||||||
Battery Voltage | 24 VDC | 24VDC | 48 VDC | 48 VDC | ||||
Floating Charge Voltage | 27 VDC | 27 VDC | 54 VDC | 54 VDC | ||||
Overcharge Protection | 33 VDC | 33 VDC | 63 VDC | 63 VDC | ||||
Charging Method | CC/CV | |||||||
Solar Charge & AC Charge | ||||||||
Solar Charge Type | MPPT | |||||||
Max. PV Array Power | 2000W | 4000W | 5000W | 5000W | ||||
Max. PV Array Open Circuit Voltage | 500 VDC | |||||||
PV Array MPPT Voltage Range | 120VDC~450 VDC | |||||||
Maximum Solar Input Current | 10A | 15A | 18A | 18A | ||||
Maximum Solar Charge Current | 60A | 80A | 80A | 80A | ||||
Maximum AC Charge Current | 40A | 60A | 60A | 60A | ||||
Maximum Charge Current | 60A | 80A | 80A | 80A | ||||
Communication Interface | USB/RS232/Dry-contact | |||||||
Environment | ||||||||
Operating Temperature | (-10℃~50℃) | |||||||
Storage Temperature | (-15℃~60℃) | |||||||
Humidity | 5% to 95% Relative Humidity (Non-condensing) | |||||||
Nature | ||||||||
Size (L*W*H) | 448mm*295mm*105mm | |||||||
Packing Size (L*W*H) | 565mm*380mm*190mm | |||||||
Gross Weight (kg) | 8.5 | 9 | 10 | 10 | ||||
Communication Method | USB/RS232/Dry Contact | |||||||
Recommend Products
Company Profile
Headquarter & Factory Location | No68, Baigongao Industrial area, Fucheng Street, Longhua District, Shenzhen, China |
Industry Experience | 12-Year Manufacturer and Trading, Alibaba Supplier |
Product Range | Solar Inverter, Solar Battery (lithium ion battery), Solar System, Solar Street Light, Solar Garden Light, Solar Wall Light, Solar Controller etc. |
Main Market | Africa, Middle East & Asia ( Ukraine, Russia, Vietnam, Pakistan, Nigeria, Kenya, South Africa, Ghana,etc.) |
Department | 2-teams Marketing Dept, 1-team R&D, 1 Manufacturing Center, 6-team producing Dept, After-sale Service Dept. |
Certificate | ISO9001:2008, CE, RoHs, SGS, TUV, EMC, FCC etc. |
Patent | Software Patent, Design Patent, Project Patent. |
Some Testing Equipments
Exhibition
Certificate
FAQ
Q1: How to choose a right inverter?
A1: Tell us your demand, then our sellers will recommend suitable inverters to you.
Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.
Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.
Q4: What is the warranty of inverter?
A4: 3 year warranty.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
Q6: what kinds of solar system do your inverter fit for?
A6: Our solar inverter is combined with solar inverter and MPPT charge controller, and it is suitable for hybrid and off grid
solar energy system.
A1: Tell us your demand, then our sellers will recommend suitable inverters to you.
Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.
Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.
Q4: What is the warranty of inverter?
A4: 3 year warranty.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
Q6: what kinds of solar system do your inverter fit for?
A6: Our solar inverter is combined with solar inverter and MPPT charge controller, and it is suitable for hybrid and off grid
solar energy system.
