              Leveling and cutting to length line machine for hot roll coils

    T44QK-8×2000 CNC HOT ROLLED STEEL SHEET UNCOILER, LEVELLER AND CUT TO       LENGTH PRODUCTION LINE

 This equipment is used for uncoiling, leveling, and automatic length measuring and cutting. Electrical controlling by AC variable frequency and servo control, which has better length precision and efficiency.

1.Main technical paremeter:

1.1 Technical parameter:

1.1.1 Application material: Hot rolled steel coil Q235A;

1.1.2Tensile strength: ≤450Mpa;

1.1.3Yield strength:  ≤245Mpa;

1.1.4Material thickness: 1.6-8mm;

1.1.5Material width: 1000-2000mm(Max.);

1.1.6 Rolled coil inner dia.: 610mm;

1.1.7: Rolled coil outer dia.: 1000-2000mm(Max.)

1.1.8: Weight of rolled coil: 30 T(Max.)

1.2 Finished products parameter:

1.2.1 Tolerance: L=2m ±1.5 mm

1.2.2 Tolerance of diagonal line: L=2m ±1.5mm

1.2.3 Leveling accuracy: ±2mm/m²

2. Other technical parameter:

2.1 Power supply: 380V/50Hz/3Ph

2.2 Linear speed: below than 25m/min

2.3 Power capacity: approx.: 90KW

2.4 Cover area for production line: approx.: 21m*9m

3. Processing flow:

Transverse shearing: rolling-feeding-uncoiling-leading—leveling-fixed length(length controlling)-shearing-stacking



 Other Model of Sheet Transverse Shear Line or Cut to Lenght Machine

Model	Coil Thickness	Sheet width(mm)	Shearing precision	Coil weight(ton)
T44QK-2x650	0.3-2.0	100-650	±0.5	7
T44QK -2x800	0.3-2.0	100-800	±0.5	7
T44QK -2x1600	0.2-2	500-1600	±0.5	7/15
T44QK -2x1600	0.2-2	500-1600	±0.5	7/15
T44QK -2x1830	0.2-2	900-1800	±0.5	20
T44QK -3x1600	0.5-3	500-1600	±0.5	20
T44QK -3x1830	0.5-3	900-1800	±0.5	20
T44QK -3x2000	0.5-3	900-2000	±0.5	30
T44QK -6x1600	1~6	900-1600	±1	30
T44QK -6x2000	1~6	900-2000	±1	30
T44QK -8x2000	2~8	900-2000	±1	30
T44QK -12x2000	3~12	900-2000	±1.5	30
T44QK -16x2000	4~16	900-2000	±2	30
