Заводская цена ацетиленовые газогенераторы 20 м3 установка для производства 99.9% чистоты

Заводская цена ацетиленовые газогенераторы 20 м3 установка для производства 99.9% чистоты

Категория: >>>
Поставщик: Shandong,Bee,Gas,Energy,Tech,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	0.42 $*	0.2 $*
Aug-15-2025	0.94 $*	0.96 $*
Jul-15-2025	0.65 $*	0.67 $*
Jun-15-2025	0.19 $*	0.83 $*
May-15-2025	0.6 $*	0.43 $*
Apr-15-2025	0.8 $*	0.85 $*
Mar-15-2025	0.55 $*	0.29 $*
Feb-15-2025	0.38 $*	0.95 $*
Jan-15-2025	0.48 $*	0.25 $*

Характеристики

Factory Price 20M3 Acetylene Gas Generator Plants 99.9% Purity Acetylene Production Plant

Acetylene Plant

1. The Dissolved acetylene production plant manufactured by our factory are noted for its perfect workmanship in making advance technique in process flow, high reliability in operation, easy to operate and maintain.

2. 20M3 acetylene production plant -Main technical parameter:

Capacity: 20Nm3 /h

Purity of acetylene: C2H2>98% PH2<0.02% H2S<0.05%

Pressure at outlet of generator: 400~500mmH2O

Water temperature of generator: <65°C

Size of calcium carbide: 8~250mm

Consumption of calcium carbide: 98kg/h

Model of acetylene compressor: Z1.2-0.38/25

Electric motor for compressor: YB132M-4 B4d7.5KW

Charging pressure: 25kgf/cm2

Charging board specific: 20×2

MODEL	NRY-20	NRY-40	NRY-60	NRY-80	NRY-100	NRY-120	NRY-140	NRY-160
Acetylene Volume	20m3/h	40m3/h	60m3/h	80m3/h	100m3/h	120m3/h	140m3/h	160m3/h
Acetylen Purity	C2H2≥98%	C2H2≥98%	C2H2≥98%	C2H2≥98%	C2H2≥98%	C2H2≥98%	C2H2≥98%	C2H2≥98%
Generator outlet Pressure	<0.007Mpa	<0.007Mpa	<0.007Mpa	<0.007Mpa	<0.007Mpa	<0.007Mpa	<0.007Mpa	<0.007Mpa
Generator Water Temperature	≤70°C	≤70°C	≤70°C	≤70°C	≤70°C	≤70°C	≤70°C	≤70°C
Cac2Granularity	10-200mm	10-200mm	10-200mm	10-200mm	10-200mm	10-200mm	10-200mm	10-200mm
CaC2 Consumption	95kg/h	190kg/h	285kg/h	380kg/h	475kg/h	570kg/h	665kg/h	760kg/h
Compressor Type	M2V2-20/25	M2V2-20/25	M2V2-20/25	M2V2-20/25	M2V2-20/25	M2V2-20/25	M2V2-20/25	M2V2-20/25
Motor	5.5KW	5.5KW×2	5.5KW×3	5.5KW×4	5.5KW×5	5.5KW×6	5.5KW×7	5.5KW×8
Cylinder Filing Pressure	2.45Mpa	2.45Mpa	2.45Mpa	2.45Mpa	2.45Mpa	2.45Mpa	2.45Mpa	2.45Mpa
Filling Platform	36	72	108	144	180	216	252	288
Water Consumption	1.5m3/h	3m3/h	4.5m3/h	6m3/h	7.5m3/h	9m3/h	10.5m3/h	12m3/h
