4 полости автоматическая машина выдувного формования

4 полости автоматическая машина выдувного формования

Категория: >>>
Поставщик: Taizhou,DianYa,Intelligent,Equipment,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	0.25 $*	0.4 $*
Aug-15-2025	0.6 $*	0.92 $*
Jul-15-2025	0.40 $*	0.19 $*
Jun-15-2025	0.69 $*	0.68 $*
May-15-2025	0.24 $*	0.52 $*
Apr-15-2025	0.30 $*	0.41 $*
Mar-15-2025	0.32 $*	0.6 $*
Feb-15-2025	0.52 $*	0.33 $*
Jan-15-2025	0.68 $*	0.85 $*

Характеристики

Product Description

Product Application

Full-Automatic PET Bottle Blowing Machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc. Beverage bottle, cosmetic bottle, medicine bottle, jar etc.

SPECIFICATIONS FOR 4CAVITY AUTOMATIC SERVO BLOW MOLDING MACHINE
Main performance parameters	Clamping force	kg	22000
		clamping stroke	mm	125
		stretching stroke	mm	450
Electrical system	total power	kw	52
		heating power	kw	32x1.5kw=48
		number of lamp layers	layers	8
air system	operating pressure	kg/cm2	7-9
		low pressure air consumption	ltr/min	1600
		blowing pressure	kg/cm2	30-40

Main Features

1.Utilization of automatic central lubrication.

2.Compact space design for convenience of mold-conversion, repairing, and maintenance.

3.According to customer requirement can install air-recycle system.

4.Swift exchange design for preform mandrels.

5.Optimized air flow in the oven for stable heating process.

6.Easy to adjust, exchange and access heating oven; Protection for preform thread against heating.

7.Intact rotating robot grip with linear guider for right access, rapid motion; reducing adjustment and maintenance time.

8.Electronic inspector for ejecting faulty preform and bottles.

9.Fast,safe,and accurate cam-controlled blowing wheel for providing the best bottles.

10.Precise control of blowing technique to produce less-weighted bottle.

11.Smart design for quick conversion of blow mold.

Detailed Images

Main Features

Name: Cylinder
Brand: FESTO
Original: Germany

Machine Parts

Name: finger robot
Brand: FESTO
Original: Germany

Packing & Delivery

Packaging
Size	123 (L) * 456 (W) * 789 (D)
Weight	1.2 T
Packaging Details	The normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.

Packaging
Size	123 (L) * 456 (W) * 789 (D)
Weight	1.2 T
Packaging Details	The normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
