Характеристики
Product Description
Multi-layer hot air belt drying machine
It is a kind of continuous production.The main heating mode could choose electric ,steam ,gas and coal Its main principle is to put the material evenly spread in net,net belt with 12-60 steel mesh belt,reciprocate by dragging gear in dryer,hot air between the material flows and water vapor from moisture discharge hole,so as to achieve the purpose of drying.The dryer can be made into multi-layer type,there are one to seven layers,length:5-40 m.(We have all kinds of dryer, hot air dryer, microwave dryer, all machines can be customized.)can widely used to Pigments, traditional Chinese medicine decoction pieces, medicinal materials, dehydrated vegetables, fruits,pelleted feed, monosodium glutamate, coconut, organic plastics, synthetic rubber, acrylic fiber, pharmaceuticals, small wood products, plastic products, electronic components aging, curing, etc.
Advantages
1.8 years manufacture experience.
2.With automatic control system and computer control system to choose.
3.With electric heating,calculated on type 15 kw,practical 5-8kw / h.
4.Most hot air is circled inside the oven, high heat efficiency,save energy.
5. Equipped with forced ventilation and adjustable air distribution plates.
6.Adjustable air distributing device,uniform air volume,wind speed,ensure material dry quickly and evenly.
7.Low machine noise,balance running process,automatic temperature control system
Machine details
Dryer Drawing
Application area
echnical data:
| Item | GRT -1.2-8-3 | GRT -1.5-8-4 | GRT -1.8-11-5 |
| Layer number | 3 | 4 | 5 |
| Bandwidth(m) | 1.2 | 1.6 | 2 |
| Equipment length(m) | 8 | 8 | 11 |
| Material spread thickness(mm) | 10-80 | ||
| Heat source type | Steam,hot air,gas etc | ||
| Operating temperature(℃) | 50-170 | ||
| Steam pressure(Mpa) | 0.2-0.8 | ||
| Belt speed(m/min) | 0.3-3 | ||
| Transmission method | Chain transmission | ||
| Fan | low noise centrifugal fan | ||
| Steam consumption(kg/h) | 360-600 | 150-375 | 225-600 |
| Drying intensity(KgH20/h) | 150-450 | 75-220 | 120-300 |
| Total power | 8.8 | 9 | 16 |
| Working voltage | 380V,50Hz | ||
| Feeding | Uniformly , thickness is adjustable. | ||
| Control system | Centralized control circuit | ||
| Relative humidity | ≤85% | ||
| Environment temperature | Seasonal temperature | ||
| Environmental requirements | No excessive corrosive gas, no inflammable, explosive gas | ||
| Site requirements | Cement floor, bright and clean | ||
Company Information
About us
Our Advantages
Packaging & Shipping
The continuous drying equipment for fish best quality will be packed in nude,motor and other parts will be packed in wooden case.
It will be delivered by air,international express or by sea!
Good package will assure you recived the goods in good condition!
