Hwatel 4 коммутацией стволов oem quad двух Диапазонный усилитель сигнала с 800 900 1800 2100
- Категория: Repeaters >>>
- Поставщик: Hwatel,(Beijing),Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 189.90 $* | 193.23 $* |
| Jul-16-2025 | 153.42 $* | 156.93 $* |
| Jun-16-2025 | 186.18 $* | 190.41 $* |
| May-16-2025 | 185.31 $* | 189.70 $* |
| Apr-16-2025 | 148.18 $* | 151.47 $* |
| Mar-16-2025 | 182.62 $* | 186.9 $* |
| Feb-16-2025 | 180.93 $* | 184.39 $* |
| Jan-16-2025 | 179.62 $* | 183.77 $* |
Характеристики
GIANT Family HWATEL 1 WATT BOOSTER
| |
Single Band 1 Watt/ 30 dBm 80 dBi gain Intelligent Single LCD |  |
Dual Band 0.5 Watt/27 dBm 80 dBi gain Intelligent Dual LCD |  |
Tri Band 0.5 Watt/27 dBm 80 dBi gain Intelligent Dual LCD | |
Four Band 23 dBm 70 dBi gain Intelligent Dual LCD | |
| TRI BAND BOOSTER | |||
800M+900M+1800+2100MHZ / BAND 5, 8, 3, 1 QUAD BAND INDUSTIAL BOOSTER FOR AMERICA 23DBM 70 DB GAIN
| |||
| Technical Specification | |||
| Tech Parameter | Uplink | Downlink | |
| Frequency Range | 850MHZ / band5 900MHz / band 8 1800MHz / band 3 2100 MHz / band 1 | ||
| Output Power | 20 ±2dBm | 23 ±2dBm | |
| Gain | 65 ±2 dB | 70±2dB | |
| Ripple in Band | GSM≤4dB | ||
| Spurious Emission | 9KHz~1GHz | ≤ -36 dBm | |
| 1GHz~12.75GHz | ≤ -30 dBm | ||
| Intermodulation Products | 9KHz~1GHz | ≤ -36 dBm | |
| 1GHz~12.75GHz | ≤ -30 dBm | ||
| VSWR | ≤3 | ||
| MTBF | >50000 hours | ||
| Power Supply | AC:100~240V, 50/ 60Hz; DC:28V | ||
| Power Comsumption | 10~50W | ||
| Impedance | 50 ohm | ||
| Mechanical Specification | |||
| RF Connector | N-Female | ||
| Dimensions (D*W*H ) mm | 270x360x60 | ||
| Net weight | 8 Kg | ||
| Packing size (D*W*H ) | 470x360x150 | ||
| Environment Conditions | IP65 | ||
| Humidity | < 90% | ||
| Operating Temperature | -10℃ ~ 55℃ | ||
