 Spiral round duct forming machine  Spiral Duct Machine

1, patented mold, easy to adjust, and has its own patent, replace the mold more trouble and save the province of materials

2, high-speed synchronous cutting system

3, PLC control

4, can be on-site construction

5, can be adjusted

6, high-quality products, high-quality services

7, the system can handle galvanized sheet, aluminum

8, automatic roll out of equipment

9, can produce a variety of different diameter spiral tube

Diameter range	Φ80-Φ1500mm
Tube Length	120-8000mm
Thickness of Strip	0.4-1.2mm
Width of Strip	137-140mm
Strip Speed	1-38/min
Dimension (L x W x H):	2650*1550*2000mm
Lock seam	Outside tube, on the inside on request
Weight	2200kg
Control System	PLC automatic control
Compressed air power	0.5-0.7kmp
Electrical	380V/3PH/50HZ(According to customer’s request)
Main Motor Power	5.5kw
The power of cutting motor	4kw
Suitable Material	Aluminum, Stainless steel, Galvanized steel
