60 тонн малых дыропробивочная машина с одним коленчатым валом механических прессов для

60 ton small single crank power presses for sale
1. Steel welded body, tempering treatment, high rigidity, accuracy and stability;
2. Vertical located crankshaft, compact structure;
3. The crankshaft undergoes grinding treatment after high frequency quenching;
4. Lengthened rectangular guide-way with a surface of bronze plate;
5. Pneumatic dual balance cylinder, which balances the slide block and punch weight to reduce noise and impact;
6. PLC control and imported safety dual valve;
7. Wet clutch and hydraulic overload protector

60 ton press equipment price for sale 60 ton press equipment price for sale  60 ton press equipment price for sale

Product Introduction

The main body is welded with high quality steel plate. Then it will be heat treated and ball blasting treated to release the stress and improve the rigidity. The best boring and milling machine ensures the high precision of the body. key stamping machine 60ton 80ton 100 ton for sale

200ton JH21 punching press machine

Product Parameters

ITEM		CODE	UNIT	JH21-60
Nominal Capacity		Pe	KN	600
Slide Stroke Length		S	mm	140
Slide Stroke Speed	Fixed		spm	70
	Variable(optional)		spm	45-85
Max. Die Shut Height		H2	mm	300
Die Shut Height Adjustment		t	mm	70
Throat Depth		C1	mm	270
Distance Between Uprights		d1	mm	560
Slide Bottom Size	FB	b	mm	400
	LR	a	mm	480
Shank Hole Size	Diameter	d	mm	50
	Depth	I	mm	70
Table Size	FB	D	mm	520
	LR	C	mm	930
	Thickness	H3	mm	130

Production Workshop

PAMA CNC machine center

Large diameter gear hobbing machine

Japanese vertical lathe

CNC boring and milling machine

Japanese Five dimensional processing center

PAMA CNC machine center

Why Choose Us

Why Choose Us
More than 30 years experiences, professional R&D team and production team.
3 years warranty for the self-produced wet type pneumatic clutch.
Quick delivery: 10 days for standard machines and 30 days for customized order.
About 80% parts are self-produced. Buyer can get the right parts in farther future.
Bigger manufacturer can provide more assurance for quality and future service.

200ton punch press with die set

                            Professional team

                          Strong production capacity

Customer trust

Product Certificate

Product Packing

Main Products

JH21 series c frame press machine

Mid. Order: one unit

JW36 series H frame press machine

Mid. Order: one unit

QC11Y Guillotine shearing machine

Mid. Order: one unit
