Товар # CVS20B 20 дюймов барабанная шлифовальная машина с переменной
- Категория: Другое деревообрабатывающее оборудование >>>
- Поставщик: Chansen,Industries,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.73 $* | 0.57 $* |
| Aug-17-2025 | 0.43 $* | 0.94 $* |
| Jul-17-2025 | 0.38 $* | 0.97 $* |
| Jun-17-2025 | 0.66 $* | 0.89 $* |
| May-17-2025 | 0.27 $* | 0.86 $* |
| Apr-17-2025 | 0.52 $* | 0.77 $* |
| Mar-17-2025 | 0.51 $* | 0.2 $* |
| Feb-17-2025 | 0.30 $* | 0.67 $* |
| Jan-17-2025 | 0.89 $* | 0.32 $* |
Характеристики
Products Description
20" Variable Speed Drum Sander Item#CVS20B | ||||||||
Sanding capacity 508mm(20") wide and 100mm(4") thickness with variable speed feed control and the economy of spiral-wrapped sandpaper roll. This 20inch Drum Sander has full cast-iron construction, which provides maximum working stability and durability. The unique i-Sanding system continuously monitors the load on the drum motor and automatically regulates the speed of the conveyor motor to maintain the highest feed rate without overload. The worktable with built-in fast adjustment level helps preventing the overlap line or ridge when sanding wider stock than the drum. What’s more, it futures 1.5kw powerful drum motor, variable speed feed, wider conveyor worktable, toolless sanding belt changing design, digital readout for sanding thickness, 100mm dust port, and steel sheet stand…All of these make this drum sander is an incredible machine in the workshop. | ||||||||
Features
* Full cast-iron construction provides maximum working stability and durability
* i-Sanding system continuously monitors the load on the drum motor and automatically regulates the speed of the conveyor motor
to maintain the highest feed rate without overload
* Conveyor driving system installed on the rear of table pulls the workpiece through the drum instead of pushing
* Conveyor table is wider than drum providing large support when sanding the stock wider than drum
* Infinitely variable speed control allows the user to choose the optimal feed rate for a full range of projects
* Separate feed and drum motors provide independent control, optimizing the performance of the sander
* Toolless sanding belt take-up clips make belt changing easy and quick
* Worktable with built-in fast adjustment level helps preventing the overlap line or ridge when sanding wider stock than the
drum
* Precision-machined and dynamically balanced extruded aluminum drum is good for heat dissipating and protecting the stock
surface from heat-damage
* Powerful 1.5kw drum motor
* Digital readout for sanding depth allows the operator to reset and measure the depth easy and quick for every project
* Integrated magnetic switch and variable speed control knob are convenient to operate
* Steel sheet stand as standard
* Optional steel extension wings provide large support when sanding long board
* i-Sanding system continuously monitors the load on the drum motor and automatically regulates the speed of the conveyor motor
to maintain the highest feed rate without overload
* Conveyor driving system installed on the rear of table pulls the workpiece through the drum instead of pushing
* Conveyor table is wider than drum providing large support when sanding the stock wider than drum
* Infinitely variable speed control allows the user to choose the optimal feed rate for a full range of projects
* Separate feed and drum motors provide independent control, optimizing the performance of the sander
* Toolless sanding belt take-up clips make belt changing easy and quick
* Worktable with built-in fast adjustment level helps preventing the overlap line or ridge when sanding wider stock than the
drum
* Precision-machined and dynamically balanced extruded aluminum drum is good for heat dissipating and protecting the stock
surface from heat-damage
* Powerful 1.5kw drum motor
* Digital readout for sanding depth allows the operator to reset and measure the depth easy and quick for every project
* Integrated magnetic switch and variable speed control knob are convenient to operate
* Steel sheet stand as standard
* Optional steel extension wings provide large support when sanding long board
Details Images
Specification | ||||||||
Drum length | 508mm (20") | |||||||
Max. stock width | 1016mm (40") with two passes | |||||||
Min. stock length | 57mm | |||||||
Max. stock thickness | 100mm | |||||||
Min. stock thickness | 0.8mm (1/32") | |||||||
Extruded aluminum drum size | 125mm (Dia.) x508mm (L) | |||||||
Drum speed | 1425rpm(50hz), 1725rpm(60hz) | |||||||
Drum motor | 220v/1ph/2hp(output) | |||||||
Conveyor motor | 120w, D.C. motor | |||||||
Conveyor speed | Variable speed, 0-10 FPM | |||||||
Height adjustment | 1.5mm (1/16") per revolution | |||||||
1Dust port size | 100mm | |||||||
Sanding depth digital readout | Yes | |||||||
Magnetic switch | Yes | |||||||
Steel sheet stand | Yes | |||||||
