Характеристики
JYC High Frequency Vacuum Wood Dryer(3CBM,10KW)
Sample & Application
It can be used for thick wood drying, soft/hard wood drying, floorboard drying, hardwood drying, veneer drying, and furniture board of the secondary drying
High Frequency Drying Features:
1. Quick dehydration, eliminate internal stress, widely used.
2. High frequency heating inside and outside at the same time, the wood is heated evenly, and the moisture is balanced.
3. Combined vacuum system quickly dehydrates and stress relief, drying in seconds.
2. High frequency heating inside and outside at the same time, the wood is heated evenly, and the moisture is balanced.
3. Combined vacuum system quickly dehydrates and stress relief, drying in seconds.
Model No. | GJG-1II-10(15)B-JY | GJG-3II-10(20)B-JY | GJG-4II-20(30)B-JY | GJG-5II-20(30)B-JY | GJG-6II-20(30)B-JY | GJG-10II-30(50)B-JY | GJG-14II-30(50)B-JY | GJG-20II-50(80)B-JY | GJG-30II-100(120)B-JY | ||||||||
Capability(m3) | 1CBM | 3CBM | 4CBM | 5CBM | 6CBM | 10CBM | 14CBM | 20CBM | 30CBM | ||||||||
Power | AC 380V,50Hz,3p 4wires or custom | ||||||||||||||||
HF power | 10KW/15KW | 10KW/20KW | 20KW/30KW | 20KW/30KW | 20KW/30KW | 30KW/50KW | 50KW/80KW | 80KW/100KW | 100KW/120KW | ||||||||
Frequency | 6.78MHz/13.56MHz | ||||||||||||||||
Vacuum | -0.092MPa | ||||||||||||||||
Loading size(mm) | 2100*700*700 | 3000*1000*1000 | 4000*1000*1000 | 3000*1300*1300 | 6000*1000*1000 | 6000*1300*1300 | 8000*1300*1300 | 8000*1600*1600 | 8000*2000*2000 | ||||||||
Equipment Features:
1. Automatic control, multi-process, sensor monitoring;
2. Wood drying process automatic control, really achieves “Unattended”;
3. Multiple drying process selection, multi-sensor detection device, to ensure the quality of wood drying;
4. Intuitive Operation Interface, remote assistance support, remote maintenance, and system upgrade (optional)
2. Wood drying process automatic control, really achieves “Unattended”;
3. Multiple drying process selection, multi-sensor detection device, to ensure the quality of wood drying;
4. Intuitive Operation Interface, remote assistance support, remote maintenance, and system upgrade (optional)
We can provide customized services according to the different needs of customers.
Foshan Jiyuan High frequency woodworking Equipment Co., Ltd, brand JYC was established in 1993. And has been committed to the research and development, manufacturing, and sales of high-frequency(radio-frequency) dielectric heating technology and equipment.
Our main products include HF (RF) generator, HF board edge gluing press series, HF frame assembly series, HF wood vacuum dryer series, HF bending wood press series, HF laminate press series, etc. And these machines are widely used furniture, flooring, wood-based panels, packaging, musical instruments, handicrafts, bamboo processing, plastics, textiles, food, medicine, chemicals and many other industries and fields. Our machine has served thousands of domestic and foreign wood enterprises, as well as China and abroad have more than 20 related professional universities, that use JYC's school-use experimental equipment. We have a professional technical team and can provide expert-level technical services, 24-hour online.
Our main products include HF (RF) generator, HF board edge gluing press series, HF frame assembly series, HF wood vacuum dryer series, HF bending wood press series, HF laminate press series, etc. And these machines are widely used furniture, flooring, wood-based panels, packaging, musical instruments, handicrafts, bamboo processing, plastics, textiles, food, medicine, chemicals and many other industries and fields. Our machine has served thousands of domestic and foreign wood enterprises, as well as China and abroad have more than 20 related professional universities, that use JYC's school-use experimental equipment. We have a professional technical team and can provide expert-level technical services, 24-hour online.
JYC will continue to provide the most professional and intelligent high-frequency woodworking machinery for global wood industry users to create the greatest value for users.
