High Performance ferment equipment wine making tanks
High Performance ferment equipment wine making tanks
Profile/type
Single layer tank
Double layer tank
material
SS304 or SS316L
Volume
50L-20T (Customized)
Pressure
0-1Mpa
Tank Type
Vertical type
Structure
one layer
Inner layer+ Dimple Jacket
Cooling way
No
cooling water
PARTS DETAILS
1.Top manhole / side manhole
2.Various types of CIP cleaners
3.Sterile respirator
4.Adjustable Legs
5.Inlet and Outlet sanitary valve.
6.Thermometer (According to customer requirements ).
7.Liquid level meter and lever controller (According to customer requirements) .
9.Ladder
This type of wine fermentation tank is primarily intended for maceration of grape pomace,but it also can be used as a classic wine storage tank. The circulation pipe and spray ball enable the must be pumped over the cap, which helps the maceration. Slope bottom provides an easy discharge of liquid.The large rectangular manhole makes the emptying and cleaning of tank interior easy and simply. Cooling jacketed is for controlling the fermenting temperature perfectly.
Technical Parameter
Model
Effective volume(L)
Dimension of tank(D*H)(mm)
Total Height(mm)
Agitator speed(r/min)
RST500
500
Φ800x900
1700
(According to customer requirements)
RST1000
1000
Φ1000x1220
2100
RST2000
2000
Φ1200x1500
2500
RST3000
3000
Φ1600x1500
2600
RST4000
4000
Φ1600x1830
2900
RST5000
5000
Φ1800x2000
3150
RST6000
6000
Φ1800x2400
3600
RST8000
8000
Φ2000x2400
3700
RST10000
10000
Φ2100x3000
4300
We can customize the equipment according to customers' requirment.
More details picture
Certifications
Buyer Feedback
Packaging & Shipping
FAQ
Q1
Are you trade or manufacturer?
A
We are a factory with an international sales company specialized in support for global distributors.
Q2
Can you provide instant technical consulting services?
A
We are able to discuss technical details and offer suggestions over the phone in English. You can get the answers in minutes, instead of days.
Q3
What's the difference between Ready-To-Ship and Customized products?
A
Some of RTS standard products are in stock and ready to ship in 2-3 days. We can also quick design and make the drawings for customer requirements, then begin the production.
Q4
What is the payment terms?
A
We accept Alibaba Trade Assurance Order, also can T/T and L/C.
Q5
How to choose the shipment way?
A
It is according to the order quantity, delivery time, costs and customs policy etc. (Or decide by customers)
Q6
How about the after-sales service?
A
Fast after-sales support. Our products have a one-year warranty and free permanent consulting services.
