Powerful Waterproof DCS GSM Mobile Phone Network Booster For Car  TE1820W

 Our shipping settings are based on the United States.
If you need it, please leave your detailed shipping address.
We will adjust the shipping cost according to your specific address.
Thank you for your cooperation. If you have any questions, please contact us in time.



Brief Description:
The  High power cell phone Repeater  which can achieve the bidirectional simulated amplification of the base station uplink and downlink signal directly (without digital disposal). It is used to expand and extend the base station coverage, fill signal area where mobile signal is blind and weak. It has high output power, could cover area up to 5-6K square meters.

Features:
*Receiving and sending separation, low require for ant isolation, making it convenient for installation.
*Mini design with metal cavity filter technology inside.
*Full-duplex &dual-port design, and built-in power supply, making it convenient for installation.
*Allowing for continuous gain adjustment 31dB by 1dB step.
*ALC technology used to provide auto amplitude fixing.
*Modules structures, making it convenient for installation, debugging and maintenance.

Application:
Indoor: Shopping Malls, Hotels, Offices building ,Exhibition, Basements, Tunnels etc
Outdoor: City, Villages, Country, District, Mine, Factories and mines, Highway, Railway, Tourism Regions etc.

GSM Full band Repeater
TE-1820W
Frequency Range:
Uplink: 1710-1785MHz or Customer appoint;
Downlink:1805-1880MHz or Customer appoint;
Output Power (OP): Uplink:≥40dBm; Downlink:≥43dBm;
Gain: Uplink:85dB; Downlink:90dB;
Size: 52.5×47×19cm
Weight: 36Kg
Gain adjustable range: MGC≥30;
Gain adjustable step: 1 dB;
Gain control precision: ±1.5 dB;
VSWR: 1.4:1;
Noise figure: ≤5dB
Transmission Delay:≤1.5μS
I/O impedance: 50/N connector
Spurious emission:
(9KHz-1GHz)≤-36dBm; (1GHz-12.5GHz)≤-30dBm;
Attenuation: ≥40dBc
Guard band rejection:
BW-60≤42MHz; BW-70≤45MHz;
Ambient temperature: -15ºC-55ºC
Ambient humidity: ≤95% (no dew);
Power supply: AC230V±10%/45-55Hz;
Reliability: To the GB6993-86 standard;
Electromagnetic compatibility:To the ETS300 694-4 standard;
Panel Display: LED; Power; Uplink; Downlink; Emission,Alarm indicators;
